查询CRA06P供应商 CRA06P Vishay Dale

Thick Film Resistor Array

FEATURES Concave terminal array with square corners 8 terminal package with isolated resistors Wide ohmic range: 10R to 1M0 Lead (Pb)-free solder contacts on Ni barrier layer Pure tin plating provides compatibility with Lead (Pb)-free CRA06P Thick Film resistor array is constructed on a high and lead containing soldering processes

grade ceramic body with concave terminations. A small Compatible with "Restriction of the use of Hazardous package enables the design of high density circuits. The single

Substances" (Ro HS) directive 2002/95/EC (issue 2004)

component reduces board space, component counts and

Operating temperature range of -55°C to +150°C

assembly costs. STANDARD ELECTRICAL SPECIFICATIONS MODEL POWER RATING CIRCUIT LIMITING ELEMENT TEMPERATURE TOLERANCE RESISTANCE E-SERIES

P70°C VOLTAGE MAX. COEFFICIENT RANGE

ppm/K

CRA06P 0.0625

Jumper: Zero-Ohm-Resistor available; R ≤ 50m Ω

TECHNICAL SPECIFICATIONS

CRA06P

PARAMETER UNIT

03 CIRCUIT

Rated Dissipation at 70°C 0.0625 Limiting Element Voltage 1) Insulation Voltage (1min) Vdc/ac peak Category Temperature Range °C - 55 to + 150 Insulation Resistance > 10 10 1) Rated voltage: P*R

PART NUMBER AND PRODUCT DESCRIPTION PART NUMBER: CRA06P08310K0JTA

MODEL TERMINAL STYLE PIN CIRCUIT VALUE TOLERANCE PACKING SPECIAL

CRA06 3 = 03 R = Decimal F = ± 1% TA = RT1 up to 2 digits

K = Thousand

G = ± 2% TC = RT6 M = Million J = ± 5% 0000 = 0Ω Jumper Z = 0Ω Jumper

PRODUCT DESCRIPTION: CRA06P 08 03 473 J RT1 e3

CRA06P RT1 e3

MODEL TERMINAL COUNT CIRCUIT TYPE RESISTANCE VALUE TOLERANCE PACKING1) LEAD (Pb)-FREE CRA06P 473 = 47KΩ F = ± 1% RT1 e3 = Pure Tin 4702 = 47KΩ G = ± 2% RT6 Termination Finish 10R0 = 10Ω J = ± 5% 100 = 10Ω Z = 0Ω Jumper

000 = 0Ω Jumper

First two digits (three for 1 %) are significant. Last digit is the Please refer to table PACKING, page 10. multiplier1)

NOTE: Products can be ordered using either the Product Description or the Part Number.

www.vishay.com For Technical Questions, contact: [email protected] Document Number 31047

Revision 25-Jul-05
