TI Texas Instruments PCM3000 PCM3001 Data Sheet Manual
Summary
The PCM3000/PCM3001 is an advanced, low-cost single-chip stereo audio codec providing high-fidelity 18-bit Analog-to-Digital and Digital-to-Analog conversion using Delta-Sigma technology. This comprehensive manual offers detailed technical specifications on electrical characteristics, operating parameters up to 48 kHz, and system design considerations. It is essential for engineers developing consumer electronics such as digital mixers, car audio systems, and professional recording equipment that demands outstanding performance in a compact package.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 38 |
| File Size | 453.47 KB |
| Published | June 06, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the physical size and package type of the codec?
The PCM3000/3001 is available in a small, compact SSOP-28 package.
What advanced audio features are included?
Key features include Soft Mute, Digital De-Emphasis, and Digital Attenuation (up to 256 steps).
Does the codec support various signal formats?
Yes, it supports seven alternate formats and can operate at sample rates from 4 kHz to 48 kHz.
What are the usage restrictions for this chip?
It is not intended for use in military or automotive applications unless specifically designated by Texas Instruments.
