10-BIT 50 MSPS IF SAMPLING COMMUNICATIONS

ANALOG-TO-DIGITAL CONVERTER

SLAS278 – APRIL 2000

features applications 50 MSPS Maximum Sample Rate Wireless Local Loop 10-Bit Resolution Wireless Internet Access No Missing Codes Cable Modem Receivers On-Chip Sample and Hold Medical Ultrasound 73 d B Spurious Free Dynamic Range at Magnetic Resonant Imaging fin = 15.5 MHz

48 PHP PACKAGE

5 V Analog and Digital Supply

(TOP VIEW)

3 V and 5 V CMOS Compatible Digital Output 9.7 Bit ENOB at f IN = 31 MHz 60 d B SNR at f IN = 31 MHz 82 MHz Bandwidth

AVSS NC

Internal or External Reference

AVDD NC

Buffered 900 Ω Differential Analog Input VIN+ D0

VIN– D1

description

AVDD D2 VREFOUT– D3

The THS1050 is a high speed low noise 10-bit

VREFIN– D4

CMOS pipelined analog-to-digital converter. A

VREFIN+ D5

differential sample and hold minimizes even order

VREFOUT+ D6

harmonics and allows for a high degree of

VBG D7

common mode rejection at the analog input. A

AVSS D8

buffered analog input enables operation with a

AVDD D9

constant analog input impedance, and prevents

transient voltage spikes from feeding backward to

the analog input source. Full temperature DNL performance allows for industrial application with the assurance of no missing codes. The typical integral nonlinearity (INL) for the THS1050 is less than one LSB. The superior INL curve of the THS1050 results in SFDR performance that is exceptional for a 10-bit analog-to-digital converter. The THS1050 can operate with either internal or external references. Internal reference usage selection is accomplished simply by externally connecting reference output terminals to reference input terminals.

AVAILABLE OPTIONS

PACKAGE

TA 48-TQFP

(PHP)

–40°C to 85°C THS1050I 0°C to 70°C THS1050C

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date. Copyright  2000, Texas Instruments Incorporated

Products conform to specifications per the terms of Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.

1POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
