Texas Instruments TPS68000 User's Guide and Manual
Summary
The TPS68000 is a highly efficient full-bridge phase shift controller engineered specifically for CCFL backlight applications. This manual details the device's operation across a wide input voltage range (8V to 30V) and covers sophisticated features like smart dimming, synchronizable Master-Slave configurations, and robust protection circuits. It is ideal for electronics designers creating high-performance backlighting power supplies for monitors, LCD TVs, और portable digital displays requiring maximum efficiency and reliability.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 23 |
| File Size | 870.52 KB |
| Published | June 02, 2026 |
