Texas Instruments CD54HC08, CD74HC08, CD54HCT08, CD74HCT08 Specifications and User's Manual
Summary
This technical guide provides detailed specifications and compatibility information for a series of high-speed CMOS Logic AND Gates (Quad 2-Input AND Gate). The line features include low power consumption, buffered inputs, and wide operating temperature ranges, making them ideal for modern digital circuits. This resource is essential for electronic engineers and hardware designers who need to select components that meet rigorous performance criteria, ensuring accurate integration into complex systems ranging from -55°C to 125°C environments.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 15 |
| File Size | 462.55 KB |
| Published | June 22, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What operating temperature range should be expected for these logic gates?
The devices feature a wide operational temperature range of -55°C to 125°C.
Are these ICs protected against static electricity during handling?
No, the datasheet cautions that these devices are sensitive to electrostatic discharge and proper IC Handling Procedures must be followed.
Which logic standard is guaranteed compatibility with these gates?
The CD54H series provides compatibility with the standard 74LS logic family. The CD74HC series offers direct LSTTL input compatibility.
What is the recommended supply voltage range for HC type devices?
For HC types, the device operates on a supply voltage (Vcc) range of 2V to 6V.
