Order this document

SEMICONDUCTOR TECHNICAL DATA by MPX2202/D

Motorola Preferred Device

The MPX2202/MPXV2202G device series is a silicon piezoresistive pressure sensor providing a highly accurate and linear voltage output — directly proportional to the applied pressure. The sensor is a single monolithic silicon diaphragm with the strain gauge and a thin–film resistor network integrated on–chip. The chip is laser trimmed for

0 to 200 k Pa (0 to 29 psi)

precise span and offset calibration and temperature compensation. They are designed

40 m V FULL SCALE SPAN

for use in applications such as pump/motor controllers, robotics, level indicators, medical

(TYPICAL)

diagnostics, pressure switching, barometers, altimeters, etc. Features

Temperature Compensated Over 0°C to +85°C UNIBODY PACKAGE

Easy–to–Use Chip Carrier Package Options

SMALL OUTLINE PACKAGE

Available in Absolute, Differential and Gauge Con- SURFACE MOUNT figurations Application Examples Pump/Motor Controllers Robotics MPX2202A/D

Level Indicators CASE 344

Medical Diagnostics Pressure Switching

MPXV2202GP

Barometers CASE 1369 Altimeters Figure 1 illustrates a block diagram of the internal circuitry on the stand–alone pressure sensor chip.

MPX2202AP/GP

CASE 344B

!"#) MPXV2202DP

+587 CASE 1351

PIN NUMBER Gnd N/C +Vout N/C

Figure 1. Temperature Compensated Pressure

MPX2202DP VS N/C

Sensor Schematic

CASE 344C

–Vout N/C

VOLTAGE OUTPUT versus

NOTE: Pin 1 is noted by the notch in

APPLIED DIFFERENTIAL PRESSURE

the lead.

The differential voltage output of the sensor is directly proportional to the differential pressure applied. The absolute sensor has a built–in reference vacu- um. The output voltage will decrease as vacuum, relative to ambient, is drawn on the pressure (P1) side. The output voltage of the differential or gauge sensor

increases with increasing pressure applied to the MPX2202ASX/GSX pressure (P1) side relative to the vacuum (P2) side. CASE 344F

Similarly, output voltage increases as increasing vacu-

um is applied to the vacuum (P2) side relative to the PIN NUMBER

pressure (P1) side. Gnd VS

Preferred devices are Motorola recommended choices for future use +Vout –Vout MPX2202GVP and best overall value. CASE 344D

NOTE: Pin 1 is noted by the notch in

Replaces MPX2200/D

the lead.

REV 2

For More Information On This Product, 1Motorola Sensor Device Data

 Motorola, Inc. 2002
