LINEAR TECHNOLOGY LTC3714 User's Manual
Summary
This high-efficiency synchronous step-down controller is engineered for advanced CPU power management systems. It provides highly stable, programmable output voltages ranging from 0.6V to 1.75V while supporting extreme input ranges of 4V to 36V. The accompanying manual offers comprehensive technical details on its operation, covering architectural specifics, transient response characteristics, and necessary protection features for designing reliable mobile processor power supplies. Ideal for electronics designers building high-performance computing solutions.
Manual Details
| Brand | Linear |
|---|---|
| Pages | 28 |
| File Size | 333.02 KB |
| Published | June 20, 2026 |
