IDEC SA1E Test Report Technical Document
Summary
These miniature photoelectric sensors provide highly reliable detection in industrial automation applications. Available in multiple advanced configurations—including laser, LED, through-beam, and retro-reflective types—they meet demanding operational needs. This comprehensive technical documentation details the full range of accessories, wiring options, and proves compliance with global standards (e.g., IEC/EN60947-5-2). It is essential reading for engineers and system integrators who require certified, durable components for critical industrial control systems.
Page 1 Text Content
No.OT304-JE22079
TEST REPORT
製品名： SA1E 形アンプ内蔵小形光電スイッチ Product Name： SA1E Series Miniature Photoelectric Sensors (Built-in Amplifier)/Laser Model
SA1E-□
Part Number：
12V～24V DC
Rating： Rated input voltage
適用規格： UL508 (Listing)
Applicable Standards： CSA C22.2 No.14 (c-UL Listing) IEC/EN60947-5-2
テスト結果： 合格 Test Result： Passed
備考： Remarks：
承認/ Approved by: 照査/ Checked by : 担当/ Tested by :
Masaaki Fujii Kenshiro Kozai Shuhei Yamamoto
Reliability Evaluation Group Reliability Evaluation Group Reliability Evaluation Group Quality Assurance Department Quality Assurance Department Quality Assurance Department
IDEC CORPORATION
FH304-002,2021 Page1/10
