Page 2
Table of Contents Table of Contents Product Overview ........................................................3 Troubleshooting ........................................................21 Package Conten...
Page 3
Section 1 - Product Overview Product Overview Package Contents • D-Link DHP-302 Powerline HD Ethernet Adapter • D-Link DHP-342 Powerline HD 4-Port Switch • CAT5 Ethernet Cable X 2 • Power Cord X 1 • C...
Page 4
Section 1 - Product Overview Introduction D-Link announces a fast, 200Mbps* Powerline HD 4-Port Starter Kit which allows you to connect your home computers, networking devices and gaming devices throu...
Page 5
Section 1 - Product Overview Hardware Overview DHP -302 LEDs AP LED A solid light indicates that the Power LED device is the master unit in the A solid light indicates that the device powerline networ...
Page 6
Section 1 - Product Overview Hardware Overview DHP-342 LEDs Throughput LED A solid light indicates that the Powerline device has connected to another Powerline device on the network. Green LED: Power ...
Page 7
Section 1 - Product Overview Hardware Overview Connection Push Button Security Press to secure your network. Refer to page 10 for more information. Ethernet Port Connect Ethernet-enabled device cable ...
Page 8
Section 1 - Product Overview Hardware Overview Connection Push Button Security Press to secure your network. Refer to page 10 for more information. Ethernet Ports (1-4) Power Receptor Connect Ethernet...
Page 9
Section 2 - Installation Hardware Installation Power Plug in the DHP-302 and DHP-342 into the AC wall outlets or power strip. Note: Power source is confirmed when the green LED Power Indicator on the ...
Page 10
Section 2 - Installation Push Button Security 1. All Adapters Plug in all the adapters to be configured. 2. First Adapter Select the first adapter to be configured as the AP(Access Point). Press and h...
Page 11
Section 2 - Installation Using the Setup Wizard Follow the simple steps below to run the Setup Wizard to guide you quickly through the installation process. Insert the D-Link DHP-343 CD into your CD-R...
Page 12
Section 2 - Installation Click Next Click Finish 12D-Link DHP-343 User Manual
Page 13
Section 3 - Configuration Configuration After you have completed the D-Link Powerline Utility installation wizard, double-click the D-Link Powerline HD Utility icon on your desktop to start the config...
Page 14
Section 3 - Configuration Red text on the Device Name, Network ID, MAC & Location columns mean that the powerline network is encrypted with the default Network ID (D-Link). Follow the steps below ...
Page 15
Section 3 - Configuration Setup This screen shows the current configuration of the DHP-302 or DHP-342. Device Name: Show name of devices that have been discovered. Default is Device 1, Device 2 etc (M...
Page 16
Section 3 - Configuration Quality: Network connection quality of the connected node. • Three circles - Best powerline connection. Suitable for HD video stream connection. • Two circles - Better powerl...
Page 17
Section 3 - Configuration Security This section shows the security configuration of the DHP-302 or DHP-342. You can modify any of the parameters and click Save Setting to save your configuration. Devi...
Page 18
Section 3 - Configuration Application Qo S The Quality of Service (Qo S) screen will allow you to set priorities for traffic passing through your network. By default all types of traffic are assigned ...
Page 19
Section 3 - Configuration Advanced Qo S Rule: Select the traffic type (UDP or TCP) to have priority. 802.1p use prioritization bits in Layer-2 frames. Port: Input the port number to have priority. Pri...
Page 20
Section 3 - Configuration System With the power saving mode enabled and the ethernet link activity being down for 15 minutes, the DHP-302 or DHP- 342 will automatically go into stand-by mode. When the...
Page 21
Section 4 - Troubleshooting Troubleshooting • Powerline HD utility does not start correctly: Reinstall the utility. • Powerline HD utility does not detect the Power Line HD Network Adapter: Please mak...
Page 22
Appendix A - Technical Specifications Technical Specifications Network Ports Encryption • One to Four 10/100 Ethernet ports • 3DES EMC Operation Temperature • FCC Part 15 Class B • 0°C ~ 40°C • CE Cla...
