Technical Data Input • Nominal voltage: 115/230 VAC universal (SDP4 auto select) • Power factor (PFC): as required to meet EN61000-3-2 Output • Nominal voltage: 24V (22.5-28.5VDC Adj.)

[SDP 4-24-100LT, 24V (22.5-25.7VDC Adj.)]

• Power boost: 1.4x nominal current for 2 sec. (except SDP 4-24-100LT) • Holdup time: > 25ms at Full Load (25˚C) • Tolerance: < ±2 % overall

DIN Rail Mounting Montaje en Riel DIN Montage du Rail DIN

Line regulation <0.5% Load regulation <0.5%

Snap on the DIN Rail: Atorar en en Riel DIN: Poser le Rail DIN:

Time & temp. drift <1% • Initial voltage setting: 24.5V ± 1% 1. Tilt unit as illustrated 1. Incline la unidad como 1. Incliner l’appareil

• Ripple: < 50m Vpp se ilustra comme illustré

• Power back immunity: > 35V 2. Put it onto the DIN Rail

2. Póngala sobre el Riel 2. Encliqueter sur le

• Parallel Operation: User Selectable on Front Panel (except SDP4-24-100LT)

3. Push downwards until DIN Rail DIN

• Over voltage protection: < 33VDC

stopped

[except SDP 4-24-100LT < 27VDC] 3. Empuje hacia abajo 3. Pousser vers le bas

4. Push at the lower front hasta que se detenga jusqu’à l’arrêt

Standards, Certifications edge to lock

EMC 4. Empuje de la parte 4. Appuyer sur le bord

Emissions EN 61000-6-3, Class B EN55011, EN55022 Radiated Conducted 5. Shake the unit slightly baja del frente para inférieur pour fixer to ensure that the unit asegurar

including Annex A

is secure 5. Vérifier que l’appareil

5. Mueva la unidad lig- est bien fixé

Immunity EN 61000-6-2, EN61000-4-2 Level 4, EN61000-4-3 Level 3, eramente para verificar

EN61000-4-6 Level 3, EN61000-4-4 Level 4 input and level 3 output. está segura EN61000-4-5 Isolation class 4, EN61000-4-11, Transient protection according to VDE 0160/W2 over entire load range.

Approvals EN60950, UL508 Listed, c ULus, UL 60950, c URus, CE (LVD 73/23 &

93/68/EEC), (EMC 89/336 & 93/68/EEC). EN61000-3-2, EN60079-15 (Class 1, Zone 2 hazardous location, Groups A, B, C, D w/ T3 temp class up to 60˚C Ambient.) [SDP 4-24-100LT additional approval UL 1310, class 2]

Environmental Data Ambient Temperature

• Storage/Shipment -25˚C…+85˚C

• Full nominal load -10˚C…+60˚C • Derated +60˚C…+70˚C

Degree of protection: IP20 (EN60529), Protect the unit from moisture

(and condensation)

Installation Fusing Input Internally fused.

Output Outputs are capable of providing high currents for short periods

of time for inductive load startup or switching.

Mounting Simple snap-on to DIN TS35/7.5 or TS35/15 rail system. Unit

should handle normal shock and vibration of industrial use and transportation without falling off the rail.

Connections Input/Output: screw terminals, connector size range: 20-12AWG SDP Series

(0.5-2.5mm2) for solid conductors.

This equipment is suitable for use in Class 1, Zone 2, Groups A,B,C,D or Power Supplies non-hazardous locations only. WARNING – EXPLOSION HAZARD – Substitution of components may impair suitability

for Class 1, Zone 2.

Technical Services

SDP 06-24-100T

WARNING – EXPLOSION HAZARD – Do not disconnect equipment unless power has

been switched off or the area is known to be non-hazardous. SDP 1-24-100T SDP 2-24-100T SDP 4-24-100RT SDP 4-24-100LT

Input / Entrada / Entrée utput / Salida / Sortie

Part N um ber eight (lbs/g)

úm ero de Parte Peso (lbs/g) om inal / Inrush Voltage Pow er urrent

Num éro de la Pièce Poids (lbs/g om inal / A rranque Voltaje Potencia orriente

Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]

om inale / Irruption Tensio Puissance ourant

P 06-24-100T 0.35 lbs (160g) 15W 0.6A

Typ. <35A 0.7A /0.4A / 85-264 VA

P 1-24-100T 0.5 lbs (230g) 30W 1.3A

Typ. <35A 90-375 V 1.1A /0.7A /

P 2-24-100T 0.5 lbs (230g) 50W 2.1A

Typ. <35A 2.2A /1.2A typical /

P 4-24-100R 0.8 lbs (360g) 100W 4.2A

Typ. <35A

85-132 / 176-264 VA 210-375 V

P 4-24-100LT 0.8 lbs (360g) 92W 3.8A

Typ. <35A
