Fairchild MOC205M, MOC206M, MOC207M, MOC208M Small Outline Optoisolators Transistor Output Datasheet Manual
Summary
These small outline optocouplers provide robust, high-isolation signal coupling using an infrared LED and silicon phototransistor output in a surface mountable SOIC-8 package. Ideal for engineers designing interfacing systems, critical feedback control circuits, or general switching applications that require galvanic separation between different potential sources. This manual details the technical specifications, including absolute maximum ratings, electrical parameters like CTR, and operational guidelines necessary for reliable circuit integration.
Manual Details
| Brand | Fairchild |
|---|---|
| Pages | 10 |
| File Size | 261.35 KB |
| Published | June 18, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum input-output isolation voltage?
The minimum guaranteed Input-Output Isolation Voltage is 2500 Vac(rms).
Are these components suitable for different mounting types?
Yes, they are small outline surface mountable and compatible with dual wave, vapor phase and IR reflow soldering.
What is the guaranteed minimum breakdown voltage (BV)?
The minimum BV (Breakdown Voltage) is 70 Volts for both collector-emitter and collector-base voltages.
Are there different versions available for compliance?
Yes, an optional 'V' can be added to the model number (e.g., MOC205VM) for VDE approval.
