HIGH SPEED-10 MBit/s LOGIC GATE OPTOCOUPLERS

HCPL-0600 HCPL-0601

DESCRIPTION The HCPL-0600/0601 optocouplers consist of an Al Ga AS LED, optically coupled to a very high speed integrated photo-detector logic gate with a strobable output. The devices are housed in a compact small-outline package. This output features an open collector, thereby permitting wired OR outputs. The coupled parameters are guaranteed over the temperature range of -40°C to +85°C. A maximum input signal of 5 m A will provide a minimum output sink current of 13 m A (fan out of 8). An internal noise shield provides superior common mode rejection of typically 10 k V/µs.

FEATURES Compact SO8 package

PACKAGE DIMENSIONS

Very high speed-10 MBit/s Superior CMR-10 k V/µs Fan-out of 8 over -40°C to +85°C Logic gate output

Strobable output

Wired OR-open collector

IN LA

U.L. recognized (File # E90700)

Pin 1

APPLICATIONS

Ground loop elimination 8N/C CC 0.019 (0.48)

LSTTL to TTL, LSTTL or

5-volt CMOS 0.010 (0.25)

Line receiver, data transmission 0.123 (3.13)

Data multiplexing

Switching power supplies 0.244 (6.19)

Pulse transformer replacement 0.003 (0.08)

0.021 (0.53) Computer-peripheral interface 0.011 (0.28) 0.050 (1.27)

N/C GND

Lead Coplanarity : 0.004 (0.10) MAX

Single-channel

All dimensions are in inches (millimeters)

circuit drawing

TRUTH TABLE (Positive Logic)

Input Enable Output

NC NC

A 0.1 µF bypass capacitor must be connected between pins 8 and 5. (See note 1)
