Texas Instruments XTR1064-20mA Current Transmitter with Bridge Excitation and Linearization
Summary
The XTR106 is a low-cost monolithic 4-20mA current transmitter designed for bridge sensors. This manual covers its features, including 2.5V or 5V bridge excitation, instrumentation amplification, and linearization circuitry. It is ideal for industrial process control, SCADA systems, and remote transducer applications.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 21 |
| File Size | 574.75 KB |
| Published | June 15, 2026 |
6 views
Enter the captcha to get the download link:
Frequently Asked Questions
What is the supply voltage range for the XTR106?
The XTR106 operates from 7.5V to 36V.
What output current range does the XTR106 provide?
It is a 4-20mA two-wire current transmitter.
What are the available package types for the XTR106?
It is available in 14-pin plastic DIP and SO-14 surface-mount packages.
What reference voltages does it provide for bridge excitation?
It provides 2.5V or 5V bridge excitation references.
