Texas Instruments DIT4192 192kHz Digital Audio Transmitter Data Sheet User Manual
Summary
The DIT4192 is a versatile digital audio transmitter capable of handling high-fidelity signals up to 192kHz. It features a flexible serial interface supporting I²S and master/slave operations, making it suitable for sophisticated applications across broadcast studios, mixing consoles, professional workstations, and consumer electronics. This manual provides comprehensive technical specifications, detailing compliance with industry standards (like AES-3) and outlining various operational modes for system designers and electronics engineers.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 25 |
| File Size | 538.95 KB |
| Published | June 17, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum sampling rate this transmitter supports?
It supports sampling rates up to 192kHz in hardware mode.
Can the DIT4192 operate without a microcontroller unit?
Yes, it supports both software and hardware operation making it suitable for applications with or without a microcontroller.
What voltage is required for the core supply?
The instrument requires a +5V VDD Core Supply to function.
