Texas Instruments SN75ALS170, SN75ALS170A Data Sheet
Summary
This professional manual describes the SN75ALS170 and SN75ALS170A triple differential bus transceivers—integrated circuits built for robust bidirectional communication. It provides detailed technical specifications, including operating conditions (single 5-V supply), electrical characteristics, and adherence to strict industry standards like ANSI/TIA-422-B and RS-485. Designed for noisy, multipoint bus lines, these transceivers are ideal for engineers and developers building reliable data systems requiring high-speed differential signal transmission in party-line applications.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 21 |
| File Size | 571.49 KB |
| Published | May 29, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What power supply voltage is required to operate the transceivers?
They can operate from a single 5-V power supply.
Does this device support high data transfer speeds and skew limits?
Yes, the SN75ALS170A variant supports FAST-20 SCSI and has up to 5 ns maximum skew.
How does the device handle direction control for its channels?
It features independent direction controls for each channel, and drivers/receivers use internal enables for function as a direction control.
Is this transciever suitable for noisy or long bus line applications?
Yes, it is designed for multipoint transmission on long bus lines in noisy environments and offers wide positive and negative common-mode voltage ranges.
