Texas Instruments bq2002C Data Sheet
Summary
The bq2002C is a low-cost, reliable CMOS battery-charge controller designed for safe and advanced fast charging of both NiCd and NiMH batteries. This comprehensive technical manual details the IC’s functionality, covering precise charge termination protocols (PVD or ΔV), constant-current/voltage control, temperature monitoring, and pulse-trickle capabilities. It is essential reading for electrical engineers and product designers building sophisticated battery-powered systems that require robust, integrated power management solutions.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 12 |
| File Size | 65.79 KB |
| Published | July 16, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
How does the bq2002C handle fast charge termination?
Fast charge can be terminated using negative delta voltage (-ΔV) or peak voltage detection (PVD).
What method is needed for monitoring battery temperature?
The TS pin requires a resistor-thermistor network to develop the temperature sense voltage.
How can I temporarily inhibit fast charging?
Applying a high signal to the INH (Charge inhibit) pin will suspend the fast charge process.
What is required for monitoring single-cell battery potential inputs?
The BAT input must be connected via a high-impedance resistor divider network.
