Phoenix Contact - MC 1,5 5-ST-3,5 Data Sheet / Manual
Summary
Securely connect conductors using this high-quality 5-position screw terminal block. The accompanying manual provides comprehensive technical specifications, detailing compatibility data for various wire sizes and connection methods, including bare wires and ferrules. Designed for electrical engineers and industrial automation technicians, it is an essential guide ensuring compliant and reliable wiring within control panels.
Page 1 Text Content
MC 1,5/ 5-ST-3,5
General data
Plug component, nominal current: 8 A, rated voltage: 160 V, pitch: 3.5 mm, no. of positions: 5, type of connection: Screw connection
Order number Type MC 1,5/ 5-ST-3,5
Barcode number Unit pack 50 Pcs. Customs tariff
Technical data
Dimensions / positions Height 11.1 mm Pitch 3.5 mm Dimension a 14 mm Number of positions 5 Screw thread M 2 Tightening torque 0.22 Nm
Phoenix Contact Gmb H & Co. KG Page 1/7 http://www.phoenixcontact.com Dec 15, 2003
Page Summary Contents For Phoenix Contact - MC 1,5 5-ST-3,5 Data Sheet / Manual
Manual Details
| Brand | Phoenix |
|---|---|
| Pages | 7 |
| File Size | 177.45 KB |
| Published | June 04, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum conductor cross section accepted by this terminal block?
The maximum flexible conductor cross-section is 1.5 mm², while the rigid conductor max is 1.5 mm².
Does installation require any specific tools or accessories?
Yes, a dedicated screwdriver (Item 1205037) for terminal blocks up to 1.5 mm² and a cable housing (Item 1834372) are available accessories.
What is the rated voltage and maximum current of this component?
The nominal voltage is 160 V, and the continuous nominal current capacity is 8 A.
What safety ratings are guaranteed for use?
The terminal block achieves an inflammability class according to UL 94 V0.
