Electronic Modular Switching System
Please read this manual before connecting the Electronic Modular Switching System.
ELECTRONIC MODULAR SWITCHING SYSTEM
POWER
MODEL KX-T206E
Page Summary Contents For Panasonic KX-T206E Installation Guide
Page 1
Electronic Modular Switching System Please read this manual before connecting the Electronic Modular Switching System. ELECTRONIC MODULAR SWITCHING SYSTEM POWER MODEL KX-T206E
Page 2
Thank you for purchasing the Panasonic Model KX-T206E, Electronic Modular Switching System. System Component Model No. Description Service KX-T206E Electronic Modular Switching System Telephone KX-T71...
Page 3
Important Information FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY. This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5 amp fuse is fitted i...
Page 4
Important Information This equipment should be used on PSTN lines requiring 2-wire Loop calling unguarded clearing with Loop Disconnect or DTMF address signalling. The equipment must be connected to d...
Page 5
Precaution Keep the unit away from heating appliances and electrical noise generating devices such as fluorescent lamps, motors and television. These noise sources can interfere with the perform- ance...
Page 6
Table of Contents Specifications Before Installation Unpacking Name and Location Wall Mounting Opening Front Cover Frame Ground Connection System Connection Diagram CO Line Connection Extension Connec...
Page 7
Specifications General Descriptions 1. Capacity CO line Extension 2. Control Method Stored Program CPU: 8 bits CPU Control ROM: 64 KB, Control RAM: 8 KB 3. Switching Method Space Division CMOS Crosspo...
Page 8
Before Installation Please read the following notes concerning installation and connection before installing the system. Safety Installation Instructions When installing telephone wiring, basic safety...
Page 9
Unpacking Main Unit one Screw and Washer three AC Cord one 4-pin Plug eight Name and Location Overview of the Main Unit ELECTRONIC MODULAR SWITCHING SYSTEMAC Inlet POWER Power Indicator Inside View of...
Page 10
Wall Mounting 1. Place the templet (on page 39) on the wall to mark the three screw positions. Templet 2. Install the three screws and washers (included) into the wall. 3. Hook the main unit on the sc...
Page 11
System Connection Diagram to CO1 and CO2 2 CO Lines Doorphone KX-T30865 Door Opener ELECTRONIC MODULAR SWITCHING SYSTEM Panasonic Doorphone 6 Extensions (two pair) (one pair) (two pair) KX-T7130 Singl...
Page 12
CO Line Connection Wire Specification The wire specifications are as follows: Wire Solid wire Diameter of conductor ø 0.4 – ø 0.65mm Diameter with coating ø 0.66 – ø 1.05mm Connection Use a 4-pin plug...
Page 13
Extension Connection Wire Specification The wire specifications are as follows: Wire Solid wire Diameter of conductor ø 0.4 – ø 0.65 mm Diameter with coating ø 0.66 – ø 1.05 mm Connection Use a 4-pin ...
Page 14
Paralleled Telephone Connection Any single line telephone can be connected in parallel with a proprietary telephone. 2-conductor wiring cord ELECTRONIC MODULAR SWITCHING SYSTEM POWER Connect pins “A” ...
Page 15
Installation of Optional Card and Unit Doorphone (KX-T30865) Connection DOOR OPENER EXTN. EXTN. EXTN. EXTN. EXTN. EXTN. SYSTEM CO 2 DPH GROUND 2-conductor wiring cord Panasonic KX-T30865 Notes The doo...
Page 16
Installation of Optional Card and Unit DISA Card (KX-T20691) Connection 1. Disconnect the AC cord from the system. 3. Attach the DISA card to the marked connectors. 2. Loosen the screws and remove the...
Page 17
Installation of Lightning Protectors Overview A lightning protector is a device to be installed on a CO line to prevent a dangerous surge from entering the building and damaging equipment. A dangerous...
Page 18
Installation of Lightning Protectors Outside (Main Building) Protectors (Another Building) Main Main EXTN PT Distribution Unit Frame Lightning Protector EXTNEXTN TEL TEL Earth Notice If you install an...
Page 19
Power Failure Transfer In the event of a power failure, CO2 is connected to extension 22 automatically. Note The system programmed data is protected by the factory provided lithium battery. Starting t...
Page 20
General Programming Instructions Default Setting This system has a default factory setting. If any of the program- ming needs to be changed, you can change the setting by system programming. Required ...
Page 21
System Programming System Speed Dialling Number Set Description Used to program System Speed Dial numbers. These numbers are available to all exten- sion users. There are 40 numbers from 00 through 39...
Page 22
System Programming Outgoing Permitted CO2 Assignment (Day/Night) Description Determines the extensions which can have access to CO line 2 in both day and night modes. The extension users can make outg...
Page 23
System Programming Doorphone Assignment (Day/Night) Description Assigns the extensions which will ring when a doorphone call is received and enables to call the doorphone in both day and night modes. ...
Page 24
System Programming TRS Denied Code (CLASS 2, 3) Description Allows you to specify the numbers which are toll-restricted for TRS Class 2 and Class 3. Condition The character “ ” can be any number. Inpu...
Page 25
System Programming OGM Play Description Confirms the outgoing message recorded in the OGM Recording program. Condition If you perform programming with a PT, the message “PLAYBACK” will be displayed on...
Page 26
System Programming CO2 Delayed Ringing Assignment Description Assigns delayed ringing to extensions when a call from CO line 2 is received. Condition The number of delayed rings is assigned by the “#1...
Page 27
System Programming Door Opener Assignment Description Assigns each extension to have access to door opener or not. Input Format Explanation [A]= 1 through 6 (corresponding to extension no. 21 through ...
Page 28
System Programming Other Programs Host PBX Access Code Assignment Tone Waiting Time After OGM Assigns a Host PBX access code to make an Sets the time between sending an outgoing outside call, if the s...
Page 29
System Programming Other Programs (continued) DISA Ringing Time Assignment Hookswitch Flash Time Range Sets the time to forward a call sent by the DISA Assignment feature to other extensions. If the c...
Page 30
System Programming Least Cost Routing (LCR) Programs Least Cost Routing (LCR) is a system programmable feature that automatically selects the least expensive route available at the time a long distanc...
Page 31
System Programming Least Cost Routing (LCR) Programs (continued) LCR Mode LCR Itemized Bill Code Allows you to turn on or off the Least Cost Assigns whether to register the itemized bill Routing (LCR)...
Page 32
Tone / Ring Tone <Tone> 1 sec Confirmation Tone 1 Confirmation Tone 2 Confirmation Tone 3 (Conference Tone) Dial Tone 1 Dial Tone 2 Busy Tone Reorder Tone Ringback Tone Do Not Disturb (DND) Tone...
Page 33
Tone / Ring Tone <Ring Tone> 1 sec Intercom Calls / Intercom Hold Recall CO Calls / CO Hold Recall Doorphone Calls NOTE The dial tone 2 is heard during the system programming mode and when the f...
Page 34
Programming Tables [#00] System Speed Dialling Number Set No. Phone No. (32 digits max.)Name
Page 35
Programming Tables [#01] Dial Type Selection [#12] Fax Connection Default CO1 CO2 Selection Default 0: PULSE 0: DISABLE 1: TONE 1: ENABLE [#02] Outgoing Permitted CO 1 Assignment (Day) [#72] Outgoing ...
Page 36
Programming Tables [#61] Door Opener Assignment Default Ext.21 Ext.22 Ext.23 Ext.24 Ext.25 Ext.26 0: DISABLE 1: ENABLE [#70] Day/Night Switching Mode [#71] Day/Night Starting Time Selection Default Se...
Page 37
Programming Tables [#88] LCR Route Exceptional Code Route 1 Route 2 Route 3 Route 4 No. Code (6 digits max.) No. Code (6 digits max.) No. Code (6 digits max.) No. Code (6 digits max.)
Page 39
Templet Up 71 mm 77 mm Install a screw here Install a screw here Install a screw here Copy the templet and place it on the wall.
Page 40
Panasonic Business Systems U.K. Panasonic House, Willoughby Road, Bracknell, Berkshire RG12 4FP Printed in Japan PSQX1141ZB KW0397KM1097
