National Semiconductor ADC081500 High Performance, Low Power, 8-Bit, 1.5 GSPS AD Converter Data Manual, Specification Sheet User Guide
Summary
The ADC081500 is a high-performance, low-power 8-Bit Analog-to-Digital Converter designed for digitizing signals up to 1.5 GSPS. It offers reliable operation and high resolution (7.3 ENOB) while minimizing power consumption. This manual provides comprehensive technical details on the unit's features, including robust synchronization capabilities, flexible control modes (SDR/DDR), and optimal interfacing procedures. Ideal for engineers designing professional communication systems, RF down conversion circuits, satellite test equipment, or complex instrumentation requiring precise digital signal acquisition.
Manual Details
| Brand | National |
|---|---|
| Pages | 28 |
| File Size | 802.02 KB |
| Published | June 17, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
Is the exposed pad on the package connected to ground?
Yes, the exposed pad must be soldered to the ground plane to ensure rated performance.
What is the process for initiating self-calibration?
A minimum of 80 input clock cycles logic low followed by a minimum of 80 input clock cycles high on the CAL pin initiates calibration.
How can I select between SDR or DDR output clocking?
The device supports both SDR and DDR output clocking for flexibility in data acquisition.
How do I put the ADC into a low-power state?
Applying a logic high signal to the PD pin will shift the device into Power Down Mode.
