Dual High Output Current, High Speed Amplifier

AD8017

FEATURES PIN CONFIGURATION

High Output Drive Capability 8-Lead Thermal Coastline SOIC (SO-8)

20 V p-p Differential Output Voltage, RL = 50 10 V p-p Single-Ended Output Voltage While

AD8017

OUT1 +VS

Delivering 200 m A to a 25
Load

–IN1 OUT2

Low Power Operation

+5 V to +12 V Voltage Supply @ 7 m A/Amplifier +IN1 –IN2

Low Distortion –VS +IN2

–78 d Bc @ 500 k Hz SFDR, RL = 100
, VO = 2 V p-p –58 d Bc Highest Harmonic @ 1 MHz, IO = 270 m A (RL = 10
) High Speed

160 MHz, –3 d B Bandwidth (G = +2) VS = 6V

1600 V/s Slew Rate

APPLICATIONS x DSL PCI Cards Consumer DSL Modems Line Driver Video Distribution IN -p

VS = 2.5V

PRODUCT DESCRIPTION The AD8017 is a low cost, dual high speed amplifier capable of driving low distortion signals to within 1.0 V of the supply rail.

LOAD RESISTANCE –

It is intended for use in single supply x DSL systems where low

Figure 1. Output Swing vs. Load Resistance

distortion and low cost are essential. The amplifiers will be able to drive a minimum of 200 m A of output current per amplifier.

The AD8017 drive capability comes in a very compact form.

The AD8017 will deliver –78 d Bc of SFDR at 500 k Hz, required

Utilizing ADI’s proprietary Thermal Coastline SOIC package,

for many x DSL applications. the AD8017’s total (static and dynamic) power on +12 V sup-

plies is easily dissipated without external heatsink, other than to

Fabricated in ADI’s high speed XFCB process, the high band-

width and fast slew rate of the AD8017 keep distortion to a place the AD8017 on a 4-layer PCB.

minimum, while dissipating a minimum amount of power. The

The AD8017 will operate over the commercial temperature

quiescent current of the AD8017 is 7 m A/amplifier. range –40°C to +85°C. Low distortion, high output voltage drive, and high output

current drive make the AD8017 ideal for use in low cost Cus- tomer Premise End (CPE) equipment for ADSL, SDSL, VDSL R1+ and proprietary x DSL systems.

RL = 100 LINE

VIN VREF VOUT

OR POWER IN d B

NP:NS TRANSFORMER

Figure 2. Differential Drive Circuit for x DSL Applications
