Texas Instruments TPS62230 62231 62232 Data Sheet Manual
Summary
The TPS6223X series is a high-frequency, synchronous step-down DC-DC converter designed for sophisticated battery-powered portable applications. It delivers up to 94% efficiency and supports wide voltage inputs (2.05V–6V) while maintaining excellent load regulation. This technical manual provides comprehensive details on the device's specifications, operating modes, low quiescent current consumption, and integration guidelines. Ideal for electronics designers working on devices like portable audio, digital cameras, or low-power DSP cores that require highly efficient power management with minimal size.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 28 |
| File Size | 1.30 MB |
| Published | June 05, 2026 |
