Texas Instruments TPA6102A2 Data Sheet/Manual
Summary
The TPA6102A2 is a high-efficiency stereo audio power amplifier designed for battery-powered applications. It delivers continuous output of 50 mW per channel into 16Ω loads, featuring ultra-low supply and shutdown currents. Built-in features like protection circuitry and internal gain setting streamline design and minimize external components. This document provides comprehensive technical specifications, operational details, and application guidelines necessary for engineers building compact, low-power audio equipment.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 22 |
| File Size | 609.32 KB |
| Published | July 22, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum continuous RMS power per channel into a 16-Ω load?
The device is capable of delivering 50 mW of continuous RMS power per channel.
How should the BYPASS pin be connected for optimal performance?
It must be connected to a low ESR capacitor ranging from 0.1 µF to 1 µF.
What does the SHUTDOWN pin do, and how is it activated?
It is an active-low input; when held low, the device enters a low supply current mode.
