TLE2027, TLE2037, TLE2027A, TLE2037A, TLE2027Y, TLE2037Y

EXCALIBUR LOW-NOISE HIGH-SPEED PRECISION OPERATIONAL AMPLIFIERS SLOS192A – FEBRUARY 1997 REVISED MARCH 2002 Outstanding Combination of dc Precision D, JG, OR P PACKAGE

(TOP VIEW)

and AC Performance: Unity-Gain Bandwidth 15 MHz Typ

OFFSET N1 OFFSET N2

Vn 3.3 n V/√Hz at f = 10 Hz Typ,. . . .

IN VCC

2.5 n V/√Hz at f = 1 k Hz Typ

IN OUT

VIO 25 µV Max. . . .

VCC NC

AVD 45 V/µV Typ With RL = 2 kΩ,. . . 19 V/µV Typ With RL = 600 Ω Available in Standard-Pinout Small-Outline

FK PACKAGE

Package

(TOP VIEW)

Output Features Saturation Recovery Circuitry Macromodels and Statistical information

description

The TLE20x7 and TLE20x7A contain innovative NC NC circuit design expertise and high-quality process IN– VCC+ control techniques to produce a level of ac NC NC performance and dc precision previously unavail- IN+ OUT able in single operational amplifiers. Manufac- NC NC

tured using Texas Instruments state-of-the-art Excalibur process, these devices allow upgrades to systems that use lower-precision devices. In the area of dc precision, the TLE20x7 and TLE20x7A offer maximum offset voltages of 100 µV and 25 µV, respectively, common-mode rejection ratio of 131 d B (typ), supply voltage rejection ratio of 144 d B (typ), and dc gain of 45 V/µV (typ).

AVAILABLE OPTIONS

PACKAGED DEVICES

VIOmax AT CHIP CERAMIC PLASTIC

SMALL

TA FORM‡

25°C CARRIER DIP DIP

OUTLINE†

(D) (FK) (JG) (P)

TLE2027ACD TLE2027ACP TLE2027Y

TLE2037ACD TLE2037ACP TLE2037Y

0°C to 70°C

TLE2027CD TLE2027CP TLE2027Y

TLE2037CD TLE2037CP TLE2037Y TLE2027AID TLE2027AIP

TLE2037AID TLE2037AIP

40°C to 105°C

TLE2027ID TLE2027IP

TLE2037ID TLE2037IP TLE2027AMD TLE2027AMFK TLE2027AMJG TLE2027AMP

TLE2037AMD TLE2037AMFK TLE2037AMJG TLE2037AMP

–55°C to 125°C

TLE2027MD TLE2027MFK TLE2027MJG TLE2027MP

TLE2037MD TLE2037MFK TLE2037MJG TLE2037MP

The D packages are available taped and reeled. Add R suffix to device type (e.g., TLE2027ACDR). Chip forms are tested at 25°C only.
