Texas Instruments PCI Express Product Specifications and User Guide
Summary
These specialized bridge chips are designed for connectivity acceleration, enabling seamless transition from older bus standards to modern PCI Express technology. The manual details how these robust solutions facilitate high-throughput data transfer between architectures like legacy PCI, PCI/PCI-X, and 1394a. They offer essential compatibility and advanced power management features. This product is crucial for PC add-in card manufacturers, embedded system designers, and server builders who require reliable bandwidth expansion and modernization of their computing platforms.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 9 |
| File Size | 765.56 KB |
| Published | June 18, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the primary function of the XIO2000A chip?
It serves as a bridge, enabling seamless migration from legacy PCI to native PCI Express by bridging an x1 PCIe bus to a 32-bit, 33-/66-MHz PCI bus.
Does the XIO2000A support modern data rates?
Yes, it supports PCI Express rates of 2.5 Gbps and boasts advanced features like a built-in adaptive receiver equalizer for improved jitter tolerance.
What does the XIO2200A translate between?
The XIO2200A is a single-function bridge that transfers data and supports up to 400 Mbps between the PCI Express bus and the 1394a Open-Host Controller.
Can these components be used in military or safety-critical environments?
No. The TI products are not designed or intended for use in military/aerospace or safety-critical applications unless specifically designated as compliant by TI.
