OPA703 OPA2703

OPA703

OPA4703 OPA704

OPA703

OPA703

OPA2704

®OPA703

OPA4704 SBOS180A – MARCH 2001

CMOS, Rail-to-Rail, I/O OPERATIONAL AMPLIFIERS

FEATURES DESCRIPTION RAIL-TO-RAIL INPUT AND OUTPUT The OPA703 and OPA704 series op amps are optimized for

WIDE SUPPLY RANGE: applications requiring rail-to-rail input and output swing. Single Supply: 4V to 12V Single, dual, and quad versions are offered in a variety of Dual Supplies: ±2 to ±6 packages. While the quiescent current is less than 200µA per amplifier, the OPA703 still offers excellent dynamic perfor-

LOW QUIESCENT CURRENT: 160µA

mance (1MHz GBW and 0.6V/µs SR) and unity-gain stabil-

FULL-SCALE CMRR: 90d B

ity. The OPA704 is optimized for gains of 5 or greater and

LOW OFFSET: 160µV

provides 3MHz GBW and 3V/µs slew rate.

HIGH SPEED:

The OPA703 and OPA704 series are fully specified and

OPA703: 1MHz, 0.6V/µs

guaranteed over the supply range of ±2V to ±6V. Input

OPA704: 3MHz, 3V/ µs

swing extends 300m V beyond the rail and the output swings

Micro SIZE PACKAGES:

to within 40m V of the rail.

SOT23-5, MSOP-8, TSSOP-14

The single versions (OPA703 and OPA704) are available in

LOW INPUT BIAS CURRENT: 1p A

the Micro SIZE SOT23-5 and in the standard SO-8 surface- mount, as well as the DIP-8 packages. Dual versions

APPLICATIONS (OPA2703 and OPA2704) are available in the MSOP-8,

SO-8, and DIP-8 packages. The quad OPA4703 and

AUTOMOTIVE APPLICATIONS:

OPA4704 are available in the TSSOP-14 and SO-14 pack-

Audio, Sensor Applications, Security Systems

ages. All are specified for operation from –40°C to +85°C.

PORTABLE EQUIPMENT ACTIVE FILTERS

OPA703 OPA704

TRANSDUCER AMPLIFIER TEST EQUIPMENT

NC NC

DATA ACQUISITION

V+ OPA4703

OPA4704

+In Out

OPA703 OPA704 Out A Out D

V– NC

–In A –In D

Out V+

OPA2703 SO-8, DIP-8

+In A +In D

OPA2704

+In –In

Out A V+

+In B +In C

–In A Out B

SOT23-5

–In B –In C

+In A –In B

Out B Out C

V– +In B

TSSOP-14, SO-14

MSOP-8, SO-8, DIP-8

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date. Copyright © 2001, Texas Instruments Incorporated Products conform to specifications per the terms of Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.
