Texas Instruments CD54HC112, CD74HC112, CD54HCT112, CD74HCT112 Dual J- K Flip-Flop with Set and Reset Negative-Edge Trigger
Summary
These high-performance dual J-K Flip-Flops are essential integrated circuits designed for robust digital logic design. Featuring low power consumption and complementary outputs, they offer independent Set/Reset functions, wide operating temperature ranges (-55°C to 125°C), and enhanced noise immunity. This technical manual provides comprehensive details on the various HC and HCT variants, including pinouts, electrical characteristics, voltage compatibility (2V–6V), and usage guidelines for electronics engineers building reliable, robust digital control systems.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 17 |
| File Size | 533.51 KB |
| Published | June 17, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What supply voltage range does the HC type support?
The HC types operate from 2V to 6V supply voltage.
When do these flip-flops change state?
They change state on the negative-going transition of the clock pulse.
What happens if both Set and Reset go High simultaneously?
Output states are unpredictable if both S and R go High after both being low.
What is the operating temperature range?
The operating temperature range is -55°C to 125°C.
