LZ23J3V

1/2.7-type Interline Color CCD Area LZ23J3V Sensor with 1 310 k Pixels

DESCRIPTION PIN CONNECTIONS The LZ23J3V is a 1/2.7-type (6.72 mm) solid-state

16-PIN SHRINK-PITCH WDIP TOP VIEW

image sensor that consists of PN photo-diodes and CCDs (charge-coupled devices). With

1OD OS

approximately 1 310 000 pixels (1 344 horizontal x 971 vertical), the sensor provides a stable high-

2GND GND

resolution color image.

3OFD ØV1A

FEATURES 4PW ØV1B Optical size : 6.72 mm (aspect ratio 4 : 3)

5ØRS ØV2

Interline scan format Square pixel 6NC ØV3A Number of effective pixels : 1 292 (H) x 966 (V)

Number of optical black pixels

Horizontal : 3 front and 49 rear 9ØH2 ØV4

Vertical : 3 front and 2 rear Number of dummy bits

(WDIP016-P-0500C)

Horizontal : 28 Vertical : 2 Pixel pitch : 4.2 µm (H) x 4.2 µm (V) PRECAUTIONS R, G, and B primary color mosaic filters The exit pupil position of lens should be 15 to 50 Supports monitoring mode mm from the top surface of the CCD. Low fixed-pattern noise and lag Refer to "PRECAUTIONS FOR CCD AREA No burn-in and no image distortion SENSORS" for details. Blooming suppression structure Built-in output amplifier Built-in overflow drain voltage circuit and reset gate voltage circuit Variable electronic shutter Package : 16-pin shrink-pitch WDIP [Plastic] (WDIP016-P-0500C) Row space : 12.70 mm

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
