Panasonic AVHSB300G-Mul User Guide

Summary

The AV-HSB300G HD Analog Board is a specialized piece of broadcast equipment designed for high-definition video connectivity. This comprehensive manual provides essential operating instructions and critical safety guidelines for system integration professionals. It details proper setup, connection parameters, and electrical precautions to ensure safe and efficient use in professional A/V or broadcasting environments. Perfect for technicians who require precise knowledge regarding HD analog signal handling.

📄 Preview ‹ PAGE OF 9 ›

‹

Panasonic AVHSB300G-Mul User Guide - Page 1

›

Page 1 Text Content

Operating Instructions HD Analog Board

Model No. AV-HSB300G

РУ СС КИ ES PA IT AL IA FR AN ÇA IS EU TS CH EN LI SH

Before operating this product, please read the instructions carefully and save this manual for future use.

Page Summary Contents For Panasonic AVHSB300G-Mul User Guide

Page 1 Operating Instructions HD Analog Board Model No. AV-HSB300G РУ СС КИ ES PA IT AL IA FR AN ÇA IS EU TS CH EN LI SH Before operating this product, please read the instructions carefully and save this ma...

Page 2 ENGLISH VERSION Safety precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO S...

Page 3 Safety precautions IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions li...

Page 4 Safety precautions Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households) This symbol on the products and/or accompanying documents means that used elect...

Page 5 1 to 5: Analog HD component input connectors [ANALOG INPUTS 1 to 5] Mounting Install this board in the multi-format live switcher AV-HS300G. <NOTES>  Be sure to ask the store or dealer where yo...

Page 6 Mounting 3 Remove the upper panel cover. Upper panel cover 4 Remove the screws (B), and remove the blank panel. Blank panel Screws (B) 5 Remove the 3 screws (C) and cable clamp. Screws (C) Cable c...

Page 7 7 Install the board securely using the screws (B) and 3 screws (C). (At this stage, install the cable clamp as well.) Screws (B) Screws (C) Cable clamp 8 Tighten the 6 screws (A) for the upper panel...

Page 8 Connections  Make the connection with the HD analog board while the power is off.  For details on connecting individual devices, refer to the respective operating instructions.  For details on oper...

Page 9 PANASONIC BROADCAST & TELEVISION SYSTEMS COMPANY UNIT COMPANY OF PANASONIC CORPORATION OF NORTH AMERICA Headquarters: Panasonic Way E-, Secaucus, NJ 009 (0) -00 EASTERN ZONE: Panasonic ...
