NX-series I/O System Unique I/O increases application quality and range
Standardization of control system Quality improvement by synchronizing data collection Flexible system con guration
Page Summary Contents For OMRON PLC Mechanical Controller IPC Multi-Axis Controller Touch Screen NX-Series EtherNet IP Coupler Unit NX-EIC202 NX-Series I O System Catalog
Page 1
NX-series I/O System Unique I/O increases application quality and range Standardization of control system Quality improvement by synchronizing data collection Flexible system con guration
Page 2
2 | NX Series I/O System Unique I/O increases application quality and The NX I/O connects sensors and actuators on production lines to optimize applications Application example Io T Traceability Measu...
Page 3
range Temperature Servo press Safety control Motion control High-speed, Simplify safety control Simplify temperature control Simplify position control systems high-precision press systems systems usin...
Page 4
4 | NX Series I/O System Simplicity for advanced control A fully integrated platform The NX I/O is used to integrate sequence, motion, analog, vision, and safety control, previously done by PLC and de...
Page 5
Feature of Sysmac One Control through One Software and One Network simplifies control system configuration Visualized sensor data IO-Link makes communication down to the sensor level visible Interface...
Page 6
6 | NX Series I/O System Synchronized control for high-speed performance Production data collection synchronized at high speed Based on an internal high-speed bus running in synchronization with the E...
Page 7
Nsyn X technology • The Nsyn X technology is provided by the Time Stamp sequence example internal high-speed bus synchronized with Ether CAT cycle the Ether CAT network. This technology is designed NJ...
Page 8
8 | NX Series I/O System Simplify system con gurations The choice is yours The modern control system demands increasing levels of flexibility. The NX I/O enables connection with various controllers th...
Page 9
Feature Wide choice: More than 100 types of I/O unit, from 2 to 32 points in one unit ∙ Digital Input/Output Units ∙ Analog Input/Output Units Types of ∙ Temperature Input Units NX I/O Units ∙ Encoder...
Page 10
10 | NX Series I/O System Downsize machines and control panels Reduce wiring time and save space Push-In Plus connections reduce the work and time required for wiring. Modular design saves space. Also...
Page 11
Corresponding to our shared Value Design for Panel concept for the specifications of products Greatly reduce wiring work with Push-In Plus terminal blocks Push-In Plus terminal blocks make wiring work...
Page 12
12 | NX Series I/O System Flexible connectivity expands system configuration possibilities One I/O system for various controllers While different machines may require different levels of controller pe...
Page 13
Features ・Multivendor compatibility The NX I/O can be connected with PLC from other vendors as well as Omron PLC ・Start a small-scale IO-Link IO-Link and other unique I/O systems can be easily integra...
Page 14
14 | NX Series I/O System Various software components help reduce programming time The Sysmac Library is a collection of software functional components that can be used in programs for the NJ/NX Machi...
Page 15
Application example (1) Load cells Press t using servo press Improve both speed and quality of the press-fit process Load data is collected in synchronization with the CPU cycle for high-speed measur...
Page 16
16 | NX Series I/O System Application example (2) Temperature control Packaging machines and molding machines (Temperature/motion/weighing) Reduce material and design costs to implement temperature co...
Page 17
Application example (3) Photoelectric sensors and proximity sensors Improving system commissioning and changeover efficiency Reduce work by individual identification IO-Link sensors allow you to check...
Page 18
18 | NX Series I/O System Application example (4) Traceability using RFID Improving system commissioning efficiency Reduce time required for system design and wiring Distributed installation of RFID u...
Page 19
Slave Terminals NX Series Ordering Information Applicable standards Refer to the OMRON website (www.ia.omron.com) or ask your OMRON representative for the most recent applicable standards for each mod...
Page 20
Slave Terminals NX Series Specifications Product Name Internal I/O Rated input Model Number I/O refreshing method ON/OFF response time of points common voltage DC Input Unit Switching Synchronous I/O ...
Page 21
Slave Terminals NX Series Specifications ON/OFF Product Name Internal I/O Maximum value Rated Model Number I/O refreshing method response of points common of load current voltage Transistor Output Uni...
Page 22
Slave Terminals NX Series Connection Patterns for Connector-Terminal Block Conversion Units Pattern Configuration Number of connectors Branching Connecting Cable Connector-Terminal Block Conversion Un...
Page 23
Slave Terminals NX Series I/O Number of Connection Connecting Connector-Terminal Block Wiring Common Unit Polarity capacity connectors pattern Cable * Conversion Unit method terminal XW2Z-@@@K XW2K-40...
Page 24
Slave Terminals NX Series Connection Patterns for I/O Relay Terminals Number of Pattern Configuration Branching connectors Connecting Cable I/O Relay Terminal 2 branches I/O Relay Terminal I/O Relay T...
Page 25
Slave Terminals NX Series I/O Number of Connection Number of Connecting Cable Unit Polarity I/O Relay Terminal Wiring method capacity connectors pattern branches *1 None XW2Z-RI G7TC-OC16-1 Phillips s...
Page 26
Slave Terminals NX Series I/O Number of Connection Number of Connecting Cable Unit Polarity I/O Relay Terminal Wiring method capacity connectors pattern branches *1 None XW2Z-R G7TC-ID16 Phillips scre...
Page 27
Slave Terminals NX Series High-speed Analog Input Units Specification Product Trigger input section I/O Input Input Conversion Model Number name Resolution refreshing Number of Internal I/O of points ...
Page 28
Slave Terminals NX Series Analog Output Units Specification Product Output setting value, Over all Conversion I/O refreshing Model Number name Input range Resolution decimal number accuracy of points ...
Page 29
Slave Terminals NX Series ● Temperature Input Units Specification Product name Resolution Over all accuracy Conversion I/O refreshing Model Number Input type Terminals of points (25°C) (25°C) time met...
Page 30
Slave Terminals NX Series Load Cell Input Unit Specification Product name Model Number of Conversion Load cell excitation I/O refreshing method * Input range points cycle voltage Load Cell Input Unit ...
Page 31
Slave Terminals NX Series Cables and Connectors for Line Driver Output Units with MIL Connectors Product name Specifications Model MIL Connectors type (Push-In Plus) 34 terminals XW2K-34G-T Connector-...
Page 32
Slave Terminals NX Series RFID Units Product name Amplifier/Antenna No. of unit numbers used Model RFID Unit (1Ch) NX-V680C1 V680 series RFID Unit (2Ch) NX-V680C2 IO-Link Master Unit Specification Pro...
Page 33
Slave Terminals NX Series Optional Products and Maintenance Products Product name Specification Model Unit/Terminal Block For 10 Units NX-AUX02 Coding Pins (Terminal Block: 30 pins, Unit: 30 pins) One...
Page 34
Safety Control Units NX Series Ordering Information Safety CPU Units Specification Unit type Appearance Number of safety I/O refreshing Model Maximum number of Program capacity Unit version safety I/O...
Page 35
Safety Control Units NX Series Optional Products Product Name Specification Model For 10 Units Unit/Terminal Block Coding Pins NX-AUX02 (Terminal Block: 30 pins, Unit: 30 pins) Specification Product n...
Page 37
Terms and Conditions Agreement Read and understand this catalog. Please read and understand this catalog before purchasing the products. Please consult your OMRON representative if you have any questi...
Page 38
Note: Do not use this document to operate the Unit. OMRON Corporation Industrial Automation Company Authorized Distributor: Kyoto, JAPAN Contact : www.ia.omron.com Regional Headquarters OMRON EUROPE B...
