National DS90CR215 DS90CR216 Data Sheet
Summary
This integrated chipset provides a robust solution for high-speed, 21-bit data links, efficiently converting standard CMOS/TTL signals into differential Low Voltage Differential Signaling (LVDS) streams. The manual details the electrical characteristics, operational guidelines, and performance specifications necessary for designing reliable digital communication channels up to 1.386 Gbps. Ideal for system engineers who require high bandwidth, exceptional signal integrity, and substantial cable reduction in demanding electronic applications.
Manual Details
| Brand | National |
|---|---|
| Pages | 16 |
| File Size | 295.51 KB |
| Published | May 29, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum data throughput supported by this chipset?
The system supports a data throughput of 1.386 Gbit/s.
How does the technology reduce required cable size for long distances?
It uses multiplexing and LVDS devices, reducing conductor requirements from up to 44 down to as few as 9 conductors.
What is the operating temperature range for the device?
The recommended operating free air temperature range is −40˚C to +85˚C.
What is the power consumption in low-power or standby mode?
In Power-down mode, the total power consumption is less than 0.5 mW.
