This multi-function clamp meter is an essential professional tool designed for measuring AC/DC Voltage, Current (Amps), Resistance, and Non-Contact Voltage (NCV). This manual provides comprehensive guidance on safe usage, outlining crucial safety protocols and detailed instructions for optimal performance—including auto-ranging modes and data holding. It is ideal for electricians, technicians, and maintenance professionals needing reliable electrical measurements in tight spaces.
Page 1 Text Content
ND 4952-2 61-732-736 Instructio 9/26/06 7:01 AM Page 1
#61-732 WARNING
Read First: Safety Information Understand and follow operating instructions carefully. Use the meter only as specified in this manual; otherwise, the protection provided by the meter may be impaired.
400 AAC Clamp Meter Instruction Manual
WARNING To avoid possible electric shock, personal injury or death, follow these guidelines:
Do not use if meter appears damaged. Visually inspect the meter to ensure case is not cracked and back case is securely in place. Inspect and replace leads if insulation is damaged, metal is exposed, or probes are cracked. Pay particular attention to the insulation surrounding the connectors. Do not use meter if it operates abnormally as protection maybe impaired. Do not use during electrical storms or in wet weather. Do not use around explosive gas, dust, or vapor. Do not apply more than the rated voltage to the meter. Do not use without the battery and the back case properly installed. Remove the test leads from the circuit prior to removing battery cap. Do not attempt to repair this unit as it has no user-serviceable parts.
HOLD APO AC
Page Summary Contents For IDEAL 61-732 61-736 400 AAC Clamp Meter User Manual
Manual Details
| Brand | Ideal |
|---|---|
| Pages | 18 |
| File Size | 584.19 KB |
| Published | May 23, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What safety precautions should I follow when using the meter?
Do not use if damaged, never ground yourself during measurements, and avoid usage during electrical storms or wet weather.
How do I check if both the battery and test leads are functioning correctly?
Perform a continuity test by touching the test leads together to verify input terminal functionality, and ensure the battery and back case are properly installed before use.
What is the difference between the 61-732 and 61-736 models regarding AC measurement?
The 61-732 model uses averaging sensing, while the 61-736 model features true RMS sensing.
When should I use manual versus auto ranging mode?
The meter defaults to autoranging. Manual range is used by pressing the button and overriding auto for repeated measurements; press it once for >1 second or power off/on to return to auto.
