Fairchild FODM8061 Data Handbook
Summary
The FODM8061 is a robust optocoupler designed for reliable isolated data transmission across industrial and microprocessor systems. It provides high noise immunity, supporting 3.3V/5V logic compatibility at speeds up to 10 Mbit/sec. This device allows digital signals to communicate securely without electrical conduction or ground loops. The manual provides comprehensive specifications, safety ratings, and application details for engineers requiring safe, reliable signal isolation in critical industrial fieldbus communications.
Manual Details
| Brand | Fairchild |
|---|---|
| Pages | 12 |
| File Size | 418.22 KB |
| Published | June 20, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum data rate and immunity of this optocoupler?
It offers a guaranteed 10 Mbit/sec Date Rate (NRZ) and high common mode transient immunity (CMTi).
What temperature range can the FODM8061 operate in?(Opr T)
The operating temperature range is from -40°C to +110°C.
What safety classifications are provided for the Mini-Flat Package?
It provides various ratings including I-IV (for main voltage < 150Vrms) and I-III (for main voltage < 300Vrms).
Where should customers purchase parts to ensure authenticity?
Customers are strongly encouraged to buy parts directly from Fairchild or from Authorized Fairchild Distributors.
