Unpacking Instruction (215-250HP) 產品取出說明書 (215-250HP)
Step 1: Unscrew all the cover screws (24
screws).
Step 2: Lift the wooden box and EPE.
步驟二：將木箱及 EPE 向上取出。
Step 3: Unscrew the 12 screws that fixed the
AC motor drive to the pallet and remove 4
wooden slats.
顆)及木板壓條(4PCE)。
Step 4: Lift the AC motor drive following the
steps on the back page.
5011673600-BW20
