Unpacking Instruction 產品取出說明書
Step 1: Unscrew all the cover screws.
Step 2: Open the cover.
Step 3: Remove EPEs.
步驟三：取出上方的 EPE。
Step 4: Unscrew the four cover screws.
Step 5: Remove front cover of AC drive to
take the drive out of the box.
5011618804-BTS4
