SLOS382 − SEPTEMBER 2001

FEATURES Line Drivers Motor Drivers

Low Noise

− 2.9 p A/√Hz Noninverting Current Noise Piezo Drivers

− 10.8 p A/√Hz Inverting Current Noise

DESCRIPTION

− 2.2 n V/√Hz Voltage Noise

The THS3122/5 are low-noise, high-speed current

High Output Current, 450 m A

feedback amplifiers, with high output current drive. This

High Speed

makes them ideal for any application that requires low

− 128 MHz , −3 d B BW(RL = 50 Ω, RF = 470 Ω)

distortion over a wide frequency with heavy loads. The

− 1550 V/µs Slew Rate (G = 2, RL = 50 Ω)

THS3122/5 can drive four serially terminated video

Wide Output Swing

lines while maintaining a differential gain error less than

− 26 VPP Output Voltage, RL = 50 Ω

Low Distortion

The high output drive capability of the THS3122/5

− -80 d Bc (1 MHz, 2 VPP, G = 2)

enables the devices to drive 50-Ω loads with low

Low Power Shutdown Mode (THS3125) distortion over a wide range of output voltages: − 370-µA Shutdown Supply Current −80 −d Bc THD at 2 VPP

−75 −d Bc THD at 8 VPP

Standard SOIC, SOIC Power PAD, and TSSOP Power PAD Package The THS3122/5 can operate from ±5 V to ±15 V supply

voltages while drawing as little as 7.2 m A of supply current per channel. They offer a low power shutdown

APPLICATIONS

mode, reducing the supply current to only 370 µA. The

Video Distribution

THS3122/5 are packaged in a standard SOIC, SOIC Instrumentation Power PAD, and TSSOP Power PAD packages.

VOLTAGE NOISE AND CURRENT NOISE

THS3122 THS3125

FREQUENCY

SOIC (D) AND SOIC (D) AND

VCC = ±5 V to ±15 V SOIC Power PAD (DDA) PACKAGE TSSOP Power PAD (PWP) PACKAGE TA = 25°C

(TOP VIEW) (TOP VIEW)

In− 1 OUT VCC+

1 OUT VCC+

1 IN− 2 OUT

1 IN− 2 OUT

1 IN+ 2 IN−

In+ 1 IN+ 2 IN−

VCC− 2 IN+

VCC− 2 IN+

Vn N/C N/C GND SHUTDOWN N/C N/C

f − Frequency − k Hz
