Texas Instruments SN54LV75A SN74LV175A Data Handbook
Summary
The SN74LV175A is a high-performance quadruple D-type flip-flop engineered for stable and reliable operation in mixed-mode voltage environments (2V to 5.5V). This technical guide provides engineers with detailed specifications, including timing characteristics, packaging options, and robust compliance data for ESD and latch-up performance. It is essential documentation for applications requiring buffer/storage registers, shift registers, or pattern generation capabilities.
Manual Details
| Brand | Texas Instruments |
|---|---|
| Pages | 17 |
| File Size | 543.40 KB |
| Published | July 16, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What type of flip-flops are the LV175A devices?
They are quadruple D-type flip-flops designed for 2-V to 5.5-V V operation.
How is data transferred based on the clock signal (CLK)?
Data at the D input is transferred on the positive-going edge of the clock pulse (CLK).
What are the typical operating current limits?
The continuous output current (I O) is specified as ±25 mA, and the total continuous current through V or GND (I CC or I GND) is ±50 mA.
Are these devices suitable for military or automotive use?
No, they are neither designed nor intended for use in military/aerospace or automotive applications unless specifically designated as compliant.
