National Semiconductor CLC- CAPT- PCASM Data Capture Board User's Guide
Summary
The CLC-CAPT-PCASM Data Capture Board is an essential evaluation interface designed for engineers testing high-speed signal conversion. This device captures data from National Semiconductor Analog to Digital Converters (ADCs) and Diversity Receiver Chip Sets (DRCS). The user guide details step-by-step integration, covering hardware setup, PC software operation, and advanced data analysis using proprietary Matlab scripts. Perfect for professionals requiring precise and customizable acquisition of analog signal performance metrics.
Manual Details
| Brand | National |
|---|---|
| Pages | 15 |
| File Size | 992.44 KB |
| Published | June 17, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What total power supply is needed for the data capture board?
The board requires a single +5V supply; a 2-amp supply provides enough current for the evaluation board.
How do I install and use the necessary software?
Insert the CD-ROM into your computer’s COMM PORT #1 or #2 to run the default hardware installation, copying files to “c:nsc”.
What amplitude is recommended for the clock source input signal?
An amplitude of 10 to 16dBm is recommended when providing a low phase noise sinewave or square wave clock source.
Can this data capture board be used in life support systems?
No. Use as a critical component requires the express written approval of the president of National Semiconductor Corporation.
