National Semiconductor ADC08831 ADC08832 8-Bit Serial I/O CMOS AD Converters with Multiplexer and Sample Hold Function
Summary
This 8-bit CMOS Analog-to-Digital Converter is designed for advanced embedded systems and instrumentation. Featuring a low-pin-count serial I/O interface, it includes a configurable input multiplexer and vital Sample/Hold function to ensure accurate data acquisition. The manual details its operation in process control monitoring and sensor digitization tasks, making it ideal for engineers utilizing microprocessors, DSPs, or associated control logic requiring high performance with minimal power consumption.
Manual Details
| Brand | National |
|---|---|
| Pages | 23 |
| File Size | 491.81 KB |
| Published | June 16, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What microprocessors can these A/D Converters interface with?
They interface with the COPS family of micro-controllers, PLD’s, microprocessors, DSP’s, or shift registers.
How many channels does the converter support and what is the multiplexer feature?
It features a configurable input multiplexer for 2 channels, enabling single-ended, differential, or pseudo-differential modes.
What are the key power figures for low-power operation?
The typical power dissipation at full resolution is 8.5mW, but it can enter a low power mode of 3.0mW.
Is an external sample/hold circuit required for accurate readings?
No, it includes a track/hold function that allows the analog voltage to be sampled and held when needed.
