1x/1.5x/2x White LED Charge Pumps with
Two LDOs in 4mm x 4mm TQFN General Description Features
The MAX8645X/MAX8645Y charge pumps drive up to
Power Up to Eight LEDs
eight white LEDs with regulated constant current for uni-
Up to 30m A/LED Drive for Backlight
form intensity. The main group of LEDs (M1–M6) can be driven up to 30m A per LED for backlighting. The flash Up to 400m A Total Drive for Flash group of LEDs (F1 and F2) is independently controlled
Two Internal Low-Noise 200m A LDOs
and can be driven up to 200m A per LED (or 400m A total). Two 200m A LDOs are on-board to provide power for
94% Max/85% Avg Efficiency (PLED/PBATT) over Li+
camera functions. The LDOs’ output voltages are pin pro-
Battery Discharge
grammable to meet different camera-module require- ments. The MAX8645X and MAX8645Y differ only in LDO
0.2% Typical LED Current Matching
output voltages. By utilizing adaptive 1x/1.5x/2x charge- pump modes and very-low-dropout current regulators, Adaptive 1x/1.5x/2x Mode Switchover the MAX8645X/MAX8645Y achieve high efficiency over
Flexible Brightness Control
the full 1-cell lithium-battery voltage range. The 1MHz fixed-frequency switching allows for tiny external compo- Single-Wire, Serial-Pulse Interface (32 Steps) nents, and the regulation scheme is optimized to ensure
2-Bit Logic (Three Levels)
low EMI and low input ripple.
Thermal TA Derating Function
The MAX8645X/MAX8645Y are available in a 28-pin TQFN, 4mm x 4mm (0.8mm max height) lead-free package.
Low Input Ripple and EMI
2.7V to 5.5V Supply Voltage Range
Applications
Soft-Start, Overvoltage, and Thermal-Shutdown
Camera Phones and Smartphones
Protection
Backlighting and Flash
28-Pin TQFN, 4mm x 4mm Package
PDAs, Digital Cameras, and Camcorders
Typical Operating Circuit Ordering Information
PIN- PKG
PART TEMP RANGE
PACKAGE CODE
INPUT OUTPUT
2.7V TO 5.5V UP TO 580m A
PIN OUT 28 TQFN-EP
MAX8645XETI+ -40°C to +85°C T2844-1
10μF MAIN FLASH
IN 4mm x 4mm
MAX8645X 28 TQFN-EP GND MAX8645Y M1 MAX8645YETI+ -40°C to +85°C T2844-1
PGND 4mm x 4mm
M3 EP = Exposed paddle.
M4 +Denotes a lead-free package.
MAIN ON/OFF M5 AND DIMMING
ENM2 M6 F1
F2FLASH ON/OFF DUAL-LDO ON/OFF ENLDO LDO1 CAMERA
LDO2 MODULEDUAL-LDO
VOLTAGE 1μF1μF
SELECTION P2
SETF REFSETM Pin Configuration appears at end of data sheet.
