Page 1
Inspiron 5583 Service Manual Regulatory Model: P86F Regulatory Type: P86F001 November 2020 Rev. A01
Page 2
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of d...
Page 3
Contents Chapter 1: Before working inside your computer........................................................................... Before you begin .......................................................
Page 4
Chapter 13: Replacing the memory modules.................................................................................34 Procedure .....................................................................
Page 5
Post-requisites...................................................................................................................................................................56 Chapter 26: Removin...
Page 6
Procedure............................................................................................................................................................................82 Chapter 37: Repl...
Page 7
Prerequisites.......................................................................................................................................................................111 Procedure..........
Page 8
System setup.................................................................................................................................................................... Entering BIOS setup pro...
Page 9
Before working inside your computer NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Before you begin Steps 1. Save and close all open files ...
Page 10
After working inside your computer About this task CAUTION: Leaving stray or loose screws inside your computer may severely damage your computer. Steps 1. Replace all screws and ensure that no stray s...
Page 11
Safety instructions Use the following safety guidelines to protect your computer from potential damage and to ensure your personal safety. Unless otherwise noted, each procedure included in this docum...
Page 12
the damage. The weakened trace may take weeks or months to melt, and in the meantime may cause degradation of memory integrity, intermittent memory errors, etc. The more difficult type of damage to re...
Page 13
ESD protection summary It is recommended that all field service technicians use the traditional wired ESD grounding wrist strap and protective anti-static mat at all times when servicing Dell products...
Page 14
Recommended tools The procedures in this document may require the following tools: Phillips screwdriver #1 Flat-head screwdriver Plastic scribe Recommended tools
Page 15
Screw list NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then place them in a screw storage box. This is to ensure that the correct...
Page 16
Table 1. Screw list (continued) Component Secured to Screw type Quantity Screw image Power-button board Palm-rest and keyboard M2x2 assembly Solid-state drive/Intel Palm-rest and keyboard M2x3 Optane ...
Page 17
Removing the optical drive NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After wor...
Page 18
6. Pull the optical-drive bezel carefully to remove it from the optical drive. Removing the optical drive
Page 19
Replacing the optical drive NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After wo...
Page 20
Replacing the optical drive
Page 21
Removing the base cover NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After workin...
Page 22
4. Using a plastic scribe, pry the base cover starting from notches located at the top-left corner of the computer base. 5. Lift the base cover off the palm-rest and keyboard assembly. NOTE: The follo...
Page 23
7. Press and hold the power button for 5 seconds to ground the computer and drain the flea power. Removing the base cover
Page 24
Replacing the base cover NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After worki...
Page 25
3. Tighten the four captive screws that secure the base cover to the palm-rest and keyboard assembly. 4. Replace the five screws (M2.5x6) that secure the base cover to the palm-rest and keyboard assem...
Page 26
Post-requisites About this task Replace the optical drive. Replacing the base cover
Page 27
Removing the battery NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After working i...
Page 28
Removing the battery
Page 29
Replacing the battery NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After working ...
Page 30
Post-requisites Steps 1. Replace the base cover. 2. Replace the optical drive. Replacing the battery
Page 31
Removing the memory modules NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After wo...
Page 32
Procedure About this task NOTE: Depending on the configuration ordered, your computer may come installed with one or two memory modules. Steps 1. Locate the memory module(s) on your computer. Removing...
Page 33
2. Use your fingertips to carefully spread apart the securing-clips on each end of the memory-module slot until the memory module pops up. 3. Remove the memory module from the memory-module slot. Remo...
Page 34
Replacing the memory modules NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After w...
Page 35
2. Route the speaker cable through the routing guides on the palm-rest and keyboard assembly. 3. Connect the speaker cable to the system board. Post-requisites Steps 1. Replace the base cover. 2. Repl...
Page 36
Removing the wireless card NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After wor...
Page 37
4. Using a plastic scribe, disconnect the antenna cables from the wireless card. 5. Slide and remove the wireless card from the wireless-card slot. Removing the wireless card
Page 38
Replacing the wireless card NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your computer. After wo...
Page 39
Post-requisites Steps 1. Replace the base cover. 2. Replace the optical drive. Replacing the wireless card
Page 40
Removing the optical-drive connector board NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps in Before working inside your com...
