Dell Equal Logic Technical Article
Dell Equal Logic PS-M4110 Blade Array Technical Article
Page Summary Contents For Dell EqualLogic PS- M4110 Blade Array Technical Article
Page 1
Dell Equal Logic Technical Article Dell Equal Logic PS-M4110 Blade Array Technical Article
Page 2
THIS WHITE PAPER IS FOR INFORMATIONAL PURPOSES ONLY, AND MAY CONTAIN TYPOGRAPHICAL ERRORS AND TECHNICAL INACCURACIES. THE CONTENT IS PROVIDED AS IS, WITHOUT EXPRESS OR IMPLIED WARRANTIES OF ANY KIND. ...
Page 3
Table of contents 1 Executive summary ......................................................................................................................... 5 2 Audience ..............................
Page 4
Acknowledgements This whitepaper was produced by the PG Technical Marketing for Equal Logic Infrastructure and Networking. The team that created this whitepaper: Guy Westbrook and Tony Ansley
Page 5
1 Executive summary This paper provides guidance for incorporating a data center-in-a-box solution with the new Dell Equal Logic™ PS-M4110 Blade Array, Power Connect™ or Force10™ Blade IO Modules, and...
Page 6
4 Reference architecture overview The Storage Interoperability Lab conducted preliminary testing on a self-contained M1000e based data center-in-a-box architecture that included testing of multiple ne...
Page 7
Figure 2 Blade Chassis configuration (Front) 4.1.1 Additional configuration information Chassis Management Console (CMC) version: 4.1 Equal Logic Host Integration Tools version: 4.0 Microsoft Native M...
Page 8
4.2 IO module information LAN IO modules were installed in Fabric Slots A1 and A2 for all tests. SAN IO modules were installed in Fabric Slots B1 and B2 for all tests (except for tests involving the B...
Page 9
Figure 3 Sample MXL datacenter in a box solution LAN LAN SAN Stack SAN Stack LAN/Client Network LAN-to-Agg Uplinks
Page 10
5 Switch configuration Any of the currently available 10Gb Ethernet IO modules can be used as SAN switches within this reference architecture. The following sections provide the detailed list of CLI c...
Page 11
FTOS (conf-if-range-fo-1/33-37) port-channel-protocol LACP FTOS (conf-if-range-fo-1/33-37-lacp) port-channel 1 mode active FTOS (conf-if-range-fo-1/33-37) #no shutdown FTOS (conf-if-range-fo-1/33-37) ...
Page 12
5.2 Power Connect M8024-K 5.2.1 i SCSI Auto-Configuration The Power Connect M8024-k IO module supports the “i SCSI Auto-configuration” feature. When enabled, the switches will automatically enable lin...
Page 13
Spanning Tree is a global configuration setting for the Power Connect M8024k. Spanning Tree is enabled by default on the Power Connect M8024k. Rapid Spanning Tree (rstp) is the default mode for spanni...
Page 14
console(config-if)#channel-group 1 mode auto console(config-if)#mtu 9216 console(config-if)#exit console(config)#interface port-channel 1 console(config-if-ch1)#mtu 9216 console(config)#exit console# ...
Page 15
Create the stack on switch 2: Put ports into stacking mode. Ports 17-20 were used as stacking ports. console#configure console(config)#stack console(config-stack)#stack-port tengigabitethernet 2/0/17 ...
Page 16
5.3.2 LACP Member Port configuration: M8428-k> M8428-k>en M8428-k#conf t M8428-k (conf) #interface Extengigabitethernet 0/17 M8428-k (conf-if-te-0/17)# channel-group 2 mode active type standard ...
Page 17
6 General recommendations and guidelines • Recommend for use with general purpose small-medium sized consolidated loads. • Not recommended for purpose built heavy I/O applications. • Do not directly a...
Page 18
A. Port Map This appendix contains the port mapping information for the IOMs used during testing. During testing of each M-Series IO Module, the blade servers and PS-M4110 blade arrays remained in the...
Page 19
Figure 5 Force10 MXL External port map Figure 6 Power Connect M8024-k and M8428-k common internal port map PSM-C0P0 P5 P5 PSM-C0P1 PSM-C1P0 P6 P6 PSM-C1P1 PSM-C0P0 P13 P13 PSM-C0P1 PSM-C1P0 P14 P14 PS...
Page 20
Figure 7 Power Connect M8024-k External port map Figure 8 Power Connect M8428-k External port map
Page 21
B. Additional resources • Dell Tech Center Equal Logic Whitepapers: http://en.community.dell.com/techcenter/storage/w/wiki/2632.storage-infrastructure-and- solutions-team-publications.aspx • Dell Equa...
Page 22
