Module Description PROCONTROL PF

Mechanical Components

Protection Cabinet for 4 Stations, Remote Bus

EMC-Version

1KGF 101 089 E, Edition 04/06 89MS04/R1300

Application Description

The mechanical structure of the protection cabinet is shown

The protection cabinet is designed to house 4

in Figure 1.

PROCONTROL stations, each for a maximum of 50 PROCONTROL input, output or processing modules. For the purpose of installation, maintenance, and operation,

the cabinet is accessible from the front and the rear. The

The arrangement of the stations is shown in Figure 7. The

cabinet is designed for natural cooling. The cooling air enters

stations are coupled by the RS485 interface to the remote-

the cabinet from the front and the rear through ventilation

bus connection in a separate sub-rack

grids with filter mats in the doors and leaves it again through

The cabinet is intended for redundant power supply (cf. Figu- the roof plate which is of grid-type design (protection type re 4). IP30). The connection to the redundant remote bus is established Each cabinet has a partition wall on the left side. For single- with the modules 88FT05, 88TK05 in the form of single- or cabinet or row-type installations, the cabinet on the left end double-channel circuitry. needs an additional side wall and the one on the right end

needs a partition wall and a side wall. The lock on the door is

For provision of power supply and fusing of solenoid valves,

the optional supply module 89NG11 is available (version a built-in 3 mm two-way rod-type locking mechanism.

R0300 for 24 V solenoid valves, version R0400 for 48 V sole-

The cabinet is equipped with:

noid valves).

4 sub-racks, 24 inch wide, each for 26 electronic modules, utilization limited by the maximum power dissipation of the cabinet (cf. chapter on ”Cabinet equipment”), a power supply module for power distribution. Process connection is established via a signal distribution strip on the rear of the cable compartment. Below the signal distribution strip, the terminal strip for the solenoid valves is mounted. The EMC-proven protection cabinet is intended to be installed in dry, clean and vibration-free areas of normal industrial design. On the right side of the roof facing strips (front and rear), 4 borings are provided for attaching the cabinet designation plates. The plates are attached by means of 2.5 x 6 mm grooved drive studs.
