Rollei Actioncam 9s Data Sheet (EN)
Summary
Capture thrilling moments anywhere with this high-performance, waterproof action camera. Featuring stunning 4K video resolution, advanced electronic stabilization, and wide-angle optics for cinematic quality footage. The unit is equipped with a large touchscreen and dedicated selfie display for effortless control, making it ideal for adventurers, athletes, and travel enthusiasts. Connect via integrated WiFi to maximize your shooting possibilities, whether you are deep underwater or on the move.
Page 1 Text Content
Actioncam 9s Plus
Waterproof Actioncam with 4K video resolution with 60 fps and touchscreen as well as selfie display Wide angle lens 2.0“ touchscreen and selfie display for easy operation Electronic image stabilization from 4k/60 fps Integrated Wi Fi Incl. rechargeable 1000 m Ah battery Battery runtime of up to 85 minutes (4K) Waterproof up to 10 meters without case Incl. remote control Slot for micro SD cards for up to 64 GB storage Very sensitive sensor with good low light performance image noise reduction, anti blooming and anti smear characteristics CMOS sensor enables even better high speed and high definition recordings, especially in motion
Touch
Video mode: normal, time lapse, slow motion,
Display
fast motion, loop Photo mode: single, burst, countdown, time lapse, long exposure White balance for underwater
CMOS 4k 10 m
Sensitive, fast Video resolution water proof Wi Fi integrated Incl. Months Warranty sensor Touch Display up to 60 fps without case remote control and Replacement Selfie Display
Box Content
Rollei Actioncam 8s Plus, underwater protective case for depths of up to 40 meters, 2.4 GHz remote control, replaceable battery, 7 mounts, helmet mount, hook and loop fastener, stickers, cable ties, metal cable, USB cable and lens cloth
Technical features Image sensor 1/2.5“, 8.51 M resolution Still Image resolution 20M*, 16M*, 14M*, 10M*, 8M, 5M, 2M Video resolution 4K (3840x2160/60/30fps), 2.7K (2704x1520/30fps), 1080P
(1920x1080/120/60/30fps), 720P (1280x720/240/120/60/30fps)
Lens Wide angle lens | Aperture F = 2.8 | Focal length f: 2.75 mm Display 2.0’’ touchscreen (screen size 5.08 cm) and 1.33” selfie display Memory Slot for micro SD cards of up to SDXC 64 GB Data format Still image: JPG | Video: MOV Connectors micro USB 2.0, micro HDMI, ¼“ tripod thread Wi Fi IEEE 802.11 / b / g / n 2.4 GHz Remote Control 2.4 GHz remote control (included) Protective Case Waterproof up to 40 meters Battery life Up to 85 minutes with fully charged battery (4K) Power Replaceable lithium-ion battery (3.7 V / 1000 m Ah) Dimensions | Weight 65.5 x 43.8 x 26.5 mm | Approx. 129 g / 109 g ( without / with battery) Subject to technical changes. *Interpolated
www.rollei.com
Page Summary Contents For Rollei Actioncam 9s Data Sheet (EN)
Manual Details
| Brand | Rollei |
|---|---|
| Pages | 1 |
| File Size | 396.22 KB |
| Published | June 04, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What is the maximum depth I can film underwater?
The waterproof case protects up to 40 meters.
How long does the battery last at max resolution and frame rate?
Up to 85 minutes with a fully charged battery recording 4K/60fps.
What file formats are supported for photos and videos?
Still images are in JPG format, and videos are recorded in MOV.
Does the camera have special modes for different types of shooting?
Yes, it supports normal, time lapse, slow motion (video), and burst/long exposure (photo).
What connection ports does this model include?
It features micro USB 2.0, microHDMI, a ¼“ tripod thread, and WiFi.
