Charge-Pump for White LED and Power Supply
RN5T652 Development Specifications
Rev. 1.5
RICOH COMPANY, LTD. Electronic Devices Company
This specification is subject to change without notice.
Page Summary Contents For RICOH RN5T652 User Guide
Page 1
Charge-Pump for White LED and Power Supply RN5T652 Development Specifications Rev. 1.5 RICOH COMPANY, LTD. Electronic Devices Company This specification is subject to change without notice.
Page 2
RN5T652 Rev.1.5 Table of Contents 1. Outline 2. Feature 3. Pin Configuration 4. Block Diagram..............................................................................................................
Page 3
RN5T652 Rev.1.5 7.3 LDO1 / LDO2 Output Voltage............................................................................................................... 7.4 Others Function 8. Electrical Characte...
Page 4
RN5T652 Rev. 1.5 1. Outline RN5T652 contains constant frequency charge pump to optimize for white LED application and two low-noise LDOs. Output enable/disable, LEDs current setting and LDO output vol...
Page 5
RN5T652 Rev. 1.5 3. Pin Configuration (TOP VIEW) DIN3 LDOUT1 DIN2 VIN3 DIN1 LDOUT2 VOUT RN5T652 N.C. C1P N.C. C2P N.C. C2M N.C. IN IN IN IN 1M QFN0404-28 pin Pin No. Name Pin No. Name Pin No. Name Pin...
Page 6
RN5T652 Rev. 1.5 4. Block Diagram C2M LDO1 C1P LDOUT1 Charge Pump LDOUT2 VOUT GND2 2.2u F PGND1 Thermal Shutdown DIN1 SCL @25m A Digital STBB CC Driver (Main) @25m A DIN4 5bit DAC @25m A DIN5 CC Drive...
Page 7
RN5T652 Rev. 1.5 5. Pin Description No. Name I/O Function Notes 1 DIN3 O LED driver current control output 3 2 DIN2 O LED driver current control output 2 3 DIN1 O LED driver current control output 1 4...
Page 8
RN5T652 Rev. 1.5 6. Functional Blocks 6.1 Regulators 6.1.1 LDO1 Electrical Characteristics Operating Conditions (Unless otherwise specified) VBATT = 3.6V, CREFO = 1μF, Ta = 25℃ Symbol Parameter Condit...
Page 9
RN5T652 Rev. 1.5 6.1.2 LDO2 Electrical Characteristics Operating Conditions (Unless otherwise specified) VBATT = 3.6V, CREFO = 1μF, Ta = 25℃ Symbol Parameter Condition Min Typ Max Units 50μA＜IOUT2＜300...
Page 10
RN5T652 Rev. 1.5 6.2 Thermal Shutdown Circuit The thermal shutdown circuit is consisted of two temperature detection circuits and an op-amp. 6.2.1 Thermal Shutdown Block Diagram Temperature Temperatur...
Page 11
RN5T652 Rev. 1.5 6.3 Charge Pump RN5T652 charge pump drives up to six white LEDs and one strobe with regulated constant current for uniform intensity. 6.3.1 Block Diagram C2MC1M C2PC1P Charge Pump PGN...
Page 12
RN5T652 Rev. 1.5 6.3.2 Operation Initial and 1x mode When any channel is turned ON, charge pump output (VOUT) voltage becomes VIN1 voltage. In this time, Soft-start prevents the inrush current. As a r...
Page 13
RN5T652 Rev. 1.5 6.3.3 Protection Circuit When any DIN_ pin is floating or grounded, VOUT voltage is limited below protection voltage by gating on/off charge pump. In case any LED fails as an open cir...
Page 14
RN5T652 Rev. 1.5 6.3.6 Charge Pump Electrical Characteristics Unless otherwise specified VIN=3.6V, Ta=25℃, C1=C2=1u F, Cout=2.2u F Parameter Conditions Min Typ Max Units Charge Pump Operating Voltage ...
Page 15
RN5T652 Rev. 1.5 6.3.7 STBB Logic Input STBB input is used to control the flash LEDs without accessing I2C. When STBB is driven to "L", the flash LEDs are driven by the current set in the st...
Page 16
RN5T652 Rev. 1.5 6.5 CPU Interface RN5T652 uses I2C-Bus system for CPU connection through 2-wires. Connection and transfer system of I2C-Bus are described in the following sections. 6.5.1 Start and St...
Page 17
RN5T652 Rev. 1.5 6.5.2 Data Transmission and its Acknowledge After start condition, data is transmitted by 1byte (8bits). The number of bytes that can be transmitted per transmission is not limited. R...
Page 18
RN5T652 Rev. 1.5 6.5.4 Data Transmission Write Format The transmission format for the slave address allocated to each IC is defined by I2C-Bus standard. However transmission method of address informat...
Page 19
RN5T652 Rev. 1.5 6.5.6 Connection of I2C-Bus 2 wires of SCL and SDA are connected to I2C-Bus and used for transmitting clock pulses and data individually. All ICs connected to these two lines are desi...
Page 20
RN5T652 Rev. 1.5 6.5.7 AC Characteristics of I2C-Bus Operating Conditions (Unless otherwise specified) VBATT = 3.6V, CREFO = 1μF, Ta = 25℃ Symbol Parameter Condition Min Typ Max Units f SCL SCL Clock ...
Page 21
RN5T652 Rev. 1.5 7. Register 7.1 Register Map SDA Control Byte COMMAND DATA Function C2 C1 C0 D4 D3 D2 D1 D0 Main Luminance 31-steps 25m A / LED max. 000 00000 = off Initial value 0 0 0 0 0 Sub Lumina...
Page 22
RN5T652 Rev. 1.5 7.2 Main / Sub / Flash / Strobe Luminance Each sink current of DIN1-4, 5, 6, and 7 can be set by the code of D4-D0. LED Current (m A) Data Main Sub Flash Strobe D4 D3 D2 D1 D0 off off...
Page 23
RN5T652 Rev. 1.5 7.3 LDO1 / LDO2 Output Voltage Each output voltage of LDO1 and LDO2 can be set by the code of D3-D0. And enable/disable of the output can be individually set by D4 bit. LDO Voltage (V...
Page 24
RN5T652 Rev. 1.5 8. Electrical Characteristics 8.1 Absolute Maximum Ratings The operation exceeding “Absolute Maximum Ratings” below may cause permanent damage to the device. The operation of the devi...
Page 25
RN5T652 Rev. 1.5 8.4 DC Characteristics Digital Part Input (Input pin) SCL, SDA, STBB Operating Conditions (Unless otherwise specified) VBATT = 3.6V, CREFO = 1μF, Ta = 25℃ Symbol Parameter Condition M...
Page 26
RN5T652 Rev. 1.5 9. Additional Application Circuit (1) Dual Main 4 LEDs and Sub 2 LEDs Fig 9-1 Dual Main 4 LEDs and Sub 2 LEDs (2) Mono 5 LEDs Note*: Please connect DIN6 to GND. Fig 9-2 Mono 5 LEDs ©2...
Page 27
RN5T652 Rev. 1.5 (3) Dual Main 3 LEDs and Sub 2 LEDs Control flow chart VIN1 VOUT Start C1P 2.2μF Main LED Sub LED Flash PGND1 GPIO1 ⇒ “H” 4.7u F C1M (RN5T652 Enable) C2P Li-ion Battery 1μF Transmissi...
Page 28
RN5T652 Rev. 1.5 10. Package Information ©2009 Rev. 1.5 Page 27
