National Semiconductor LMC2001 High Precision, 6MHz Rail-to-Rail Output Operational Amplifier Data Sheet Manual User Guide
Summary
The LMC2001 is a highly accurate and stable precision operational amplifier with a robust 6MHz bandwidth. Engineered for demanding applications, this device provides exceptional performance metrics—such as high Common Mode Rejection Ratio (CMRR) and low noise—in a compact package. The manual details its versatile features, including rail-to-rail output, wide gain-bandwidth product, and ultra-low supply current consumption. It is ideal for professionals requiring precision amplification in instrument amplifiers, ADC/DAC buffers, or general 5V signal processing applications.
Manual Details
| Brand | National |
|---|---|
| Pages | 11 |
| File Size | 436.09 KB |
| Published | June 17, 2026 |
Enter the captcha to get the download link:
Frequently Asked Questions
What are the main benefits of the LMC2001's precision features?
It offers high CMRR (120dB), high PSRR (120dB), low input offset voltage (40μV), and rail-to-rail output.
What is the optimal supply voltage range for this amplifier?
The recommended operating supply voltage must be between 4.75V and 5.25V.
How versatile is the LMC2001 based on its packaging?
It is available in both a 5-pin SOT23 package and an 8-pin SOIC package for various applications.
What are the key speed specifications of this op amp?
The device has a high slew rate of 5V/µs and maintains a wide gain-bandwidth product of 6MHz.
