LMV111 Operational Amplifier with Bias Network General Description Features The LMV111 integrates rail-to-rail op amp with V+/2 bias (For 5V Supply, Typical Unless Otherwise Noted) circuit into one ultra tiny package, SC70-5 or SOT23-5. The
Resistor ratio matching 1% (typ)
core op amp of the LMV111 is an LMV321, which provides
rail-to-rail output swing, excellent speed-power ratio, 1MHz Space saving package SC70-5 SOT23-5
bandwidth, and 1V/µs of slew rate with low supply current. Industrial temp. range −40˚C to +85˚C The LMV111 reduces external component count. It is cost
Low supply current 130µA
effective solution for applications where low voltage opera-
Gain-bandwidth product 1MHz
tion, low power consumption, space saving, and reliable per-
formance are needed. It enables the design of small portable Rail-to-Rail output swing
electronic devices, and allows the designer to place the de- Guaranteed 2.7V and 5V performance vice closer to the signal source to reduce noise pickup and increase signal integrity.
Applications General purpose portable devices Active filters Mobile communications Battery powered electronics Microphone preamplifiers
Connection Diagrams
DS101262-21
