Page 1 Text Content
RELEASING THIS DRAWING WITHOUT PERMISSIONG Electronics SHOULD BEACCUSED ACCORDING TO THE LAWS ADN COMPANY RULES.
图纸为LGEPN资产，非法流通时， 根据相关法律和公司有关规定追究法律责任
SEC. PRINTING DEGREE
MATERIAL AND PRINTING DESCRIPTION LG MODEL NAME SUFFIX LANGUAGE PAGE REMARK
BRANDWORK MODEL P/NO. EXTERIER INTERIER
Post DD
WD-TH455D(0-9)
MFL69513925 Mega TOUCH 550 DOM
WD-TH255D(0-9) 材质: 70g 双层纸 32WD-TH455D5.ACN
ACN Chinese
WD-VH455D(0-9) CHI+ENG Panel
WD-VH255D(0-9) 1 ver.080216.02
1. 材质，印刷，尺寸参照作业表. 2. 印刷，文字大小和线条以LG设计基准.
<FRONT> <BACK>
3. 数字大小依据一般规格. 4. 批量生产前取的设计限度. 5. 本部品不应含有禁止物质(Pb,Cd,Hg,Cr+6,PBB,PBDE)，详细内容满足LGEPN-Z-1023.
<< NOTES >> 1. Material,printing and exterier size are refer to work tables. 2. Printing, tsxt size and line are based on LG desing film. 3. Exterier size on the drawing is cutting line. 4. Before product controlled by criteria sample. 5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,PBDE) and details Should comply with LGEPN-Z-1023.
Unit mm SCALE
MODELING DESIGNED REVIEWED CHECKED APPROVALED MANUAL,OWNER'S
DRUM-EXPORT
RELATED DRAWING
LGEPN DWG.
EFGG800069 2016.08.12 白晨光 李揆喆
1 内销排水管Hanger去除
No. MFL69513925
REV.No. REVISION DESCRIPTION DATE PREPARED APPROVALEDRER.NO. LG Electronics Inc. MFL69513925
