Page 1
Room Air Conditioner OWNER'S MANUAL Please read carefully and thoroughly this manual before operating this unit. Contact the authorized SVC man for repair or maintenance of this unit. Contact the inst...
Page 2
Safety precautions Safety Precautions To prevent injury and property damage, follow these instructions. Warning ................................2 Incorrect operation due to ignoring instructions will ...
Page 3
WARNING Ventilate before operating air conditioner Do not disassemble or modify products when gas goes out. randomly. It may cause explosion, fire and, burn. It may cause failure and electric shock. C...
Page 4
Preparation before operation How to Insert the Batteries Remove the battery cover by pulling it according to the arrow direction. Insert new batteries making sure that the and of battery are installed...
Page 5
About the remote control on the system The remote control transmits the signals to the system. Features of the Remote Control- Door Opened START/STOP BUTTON Operation starts when this button is presse...
Page 6
How to use the Operation Mode Selection button Cooling Operation Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Cooling Operation, press t...
Page 7
Auto Operation Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Auto Operation, press the Operation Mode Selection button. Each time the but...
Page 8
Healthy Dehumidification Operation Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Healthy Dehumidification Operation, press the Operation ...
Page 9
Heating Operation(Heat pump model only) Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Heating Operation, press the Operation Mode Selecti...
Page 10
Jet Cool Operation Press the Start/Stop button. The unit will respond with beep. Press the Jet Cool button to operate the speed cooling mode and the unit will operate in super high fan speed on coolin...
Page 11
PLASMA Purification Operation(Optional) Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. Press the PLASMA air purifying operation ON/OFF button. Opera...
Page 12
2nd Operation Press the Start/Stop button. The unit will respond with beep. Open the door of the remote control and press the 2nd Function button to operate functions printed in blue at of buttons. (C...
Page 13
Additional features Sleep Mode Press the Mode Auto button to set the To cancel the Sleep Mode, press the sleep Sleep time want the unit to turn off Mode Auto button several times until the star you au...
Page 14
Vertical Airflow Direction Control The up/down airflow (Vertical Airflow) can be Note: by the remote control. If you press the CHAOS swing button, the horizontal adjusted using airflow direction is ch...
Page 15
Forced Operation Operation procedures when the remote control can't be used. The operation will be started if the power button is pressed. If you want to stop operation, re-press the button. Power but...
Page 16
Telephone Control Operation(Optional) Calling from outside, you can start the air conditioner to keep the room comfortable. Even though you went out with the air conditioner on, you can turn it off us...
Page 17
Care and maintenance of the air conditioner CAUTION: Before performing any maintenance, turn off the main power to the system. Indoor Unit and Remote Control Never use any of the followings: Grille, C...
Page 18
Replacement of Purifying Filter(Option) Recomended use period About years Open panel and remove air Remove air purifying filters. filters. Insert new air purifying filters. Air filter Reinsert air fil...
Page 19
When the air conditioner is not to be used for time. going long When air conditioner is not going to be When the air conditioner is to be used again. used for long time. Operate the air conditioner on...
Page 20
Before you call for service... Save time and money! Troubleshooting Tips! Check the following points before requesting repairs or service.... If the fault persists, please contact your dealer or servi...
Page 23
P/No.: 3828A20243G Printed in Korea After reading this manual, keep it in place easily accessible to the user for future reference.
