Page 1
Room Air Conditioner OWNER'S MANUAL Please read carefully and thoroughly this manual before operating this unit. Contact the authorized SVC man for repair or maintenance of this unit. Contact the inst...
Page 2
Safety precautions Safety Precautions To prevent injury to the user or other people and property damage, the Warning ................................2 following instructions must be followed. Caution ...
Page 3
CAUTION Contact the authorized Service technician for repair or maintenance of this unit. Contact the installer for installation of this unit. The air conditioner is not intended for use by young chil...
Page 4
Preparation before operation How to Insert the Batteries Remove the battery cover by pulling it according to the arrow direction. Insert new batteries making sure that the and of battery are installed...
Page 5
About the remote control on the system The remote control transmits the signals to the system. Features of the Remote Control- Door Closed START/STOP BUTTON Operation starts when this button is presse...
Page 6
Features of the Remote Control- Door Opened ON/OFF TIMER BUTTONS Used to set the time of starting and stopping Safety Precautions operation. Signal transmitter TIME SETTING BUTTONS Used to adjust the ...
Page 7
How to use the Operation Mode Selection button Cooling Operation Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Cooling Operation, press t...
Page 8
Auto Operation Press the Start/Stop button. The unit will respond with beep. Safety Precautions Open the door on the remote control. To select Auto Operation, press the Operation Mode Selection button...
Page 9
Healthy Dehumidification Operation Press the Start/Stop button. The unit will respond with beep. Open the door on the remote control. To select Healthy Dehumidification Operation, press the Operation ...
Page 10
Heating Operation(Heat pump model only) Press the Start/Stop button. The unit will respond with beep. Safety Precautions Open the door on the remote control. To select Heating Operation, press the Ope...
Page 11
Jet Cool Operation Press the Start/Stop button. The unit will respond with beep. Press the Jet Cool button to operate the speed cooling mode and the unit will operate in super high fan speed on coolin...
Page 12
PLASMA Purification Operation(Option) Press the Start/Stop button. The unit will respond with beep. Safety Precautions Open the door on the remote control. Press the PLASMA air purifying operation ON/...
Page 13
Additional features Sleep Mode Press the Mode Auto button to set the To cancel the Sleep Mode, press the sleep Sleep time want the unit to turn off Mode Auto button several times until the star you au...
Page 14
Vertical Airflow Direction Control The up/down airflow (Vertical Airflow) can be Note: by the remote control. If you press the CHAOS swing button, the horizontal adjusted using airflow direction is ch...
Page 15
The Button Operation FORCED OPERATION The operation will be started if the power button is pressed. If you want to stop operation, re-press the button. FORCED OPERATION Heat pump Model Cooling Model R...
Page 16
Care and maintenance of the air conditioner CAUTION: Before performing any maintenance, turn off the main power to the system. Indoor Unit and Remote Control Never use any of the followings: Grille, C...
Page 17
Replacement of Purifying Filter(Option) Recomended use period About years Open panel and remove air Remove air purifying filters. filters. Insert new air purifying filters. Air filter Reinsert air fil...
Page 18
When the air conditioner is not to be used for time. going long When air conditioner is not going to be When the air conditioner is to be used again. used for long time. Safety Precautions Operate the...
Page 19
Before you call for service... Save time and money! Troubleshooting Tips! Check the following points before requesting repairs or service.... If the fault persists, please contact your dealer or servi...
Page 20
P/No.: 3828A20033A Printed in Korea
