Leica SR20
User Manual Version 1.0 English
Page Summary Contents For Leica SR20 User Guide and Manual
Page 1
Leica SR20 User Manual Version 1.0 English
Page 2
Introduction Leica SR20 Symbols Congratulations on your purchase of a new Leica The symbols used in this User Manual have the following SR20. meanings: DANGER: This manual contains important safety In...
Page 3
View of chapters 1. General Information 2. Description of the System.......................................................... 3. Hardware and Software Setup 4. Care and Transport 5. Safety Directions...
Page 4
Table of Contents 1. General Information.................................5 5. Safety Directions The Leica SR20....................................................... Intended use of product Overview o...
Page 5
1. General Information For decades, Leica Geosystems has enjoyed a worldwide Leica Geosystems offers an entire product basket of GPS technological lead in the manufacture of classical receivers. This ...
Page 6
The Leica SR20 Overview of the User Manual The Leica SR20 GPS receiver was designed to provide the The User Manual is intended to provide information Land Surveying community with a reliable, rugged a...
Page 7
2. Description of the System Unpacking the SR20 Standard Package Take the product out of the transport case and check that it is complete: SR20 Handheld GPS Receiver SR20 Soft Case GEB90 Battery, Li-I...
Page 8
GPS Receiver Receiver Hardware The GPS Receiver receives the GPS signal from the In most cases, a short introduction in the use of the NAVSTAR satellites and calculates a range to all visible Receiver...
Page 9
Charge the Batteries It is normal for the battery to become warm during charging. Using the chargers recommended by Leica Your Leica SR20 is powered by a rechargeable 7.2 V, Li- Geosystems, it is not ...
Page 10
Set Up the Equipment Post-processing software For best performance, GPS data collection requires undis- The Post-processing software is used to process the turbed satellite signal reception. This mean...
Page 11
3. Hardware and Software Setup Introduction “Hardware and Software Setup” is designed to help get the Hardware beginning user up and running with their new Leica SR20. Leica SR20 For more information ...
Page 12
Leica Geo Office Post-processing software Receiver Hardware Leica Geo Office is used for data post processing. Please Leica SR20 Sensor refer to the “Getting Started Guide” for more details. The Leica...
Page 13
4. On the keypad, depress the Power Button Powering Up the Unit in the Lower Left corner. Startup will be The SR20 operates on a single battery. Once a battery is followed by an audible tone, then aft...
Page 14
4. Care and Transport Transport Storage When dispatching the equipment, always use the Temperature limits complete original Leica Geosystems packaging (-40°C to +70°C / -40°F to +158°F) (case and card...
Page 15
Cleaning and drying Use only a clean, soft, lint-free cloth for cleaning. If necessary, moisten the cloth with pure alcohol. Use no other liquids; these may attack the polymer compo- nents. Damp produ...
Page 16
5. Safety Directions The following directions should enable the person respon- Adverse uses sible for the product, and the person who actually uses the Use of the product without instruction equipment...
Page 17
Limits of use Responsibilities See chapter "Technical Data". Area of responsibility for the manufacturer of the orig- inal equipment Leica Geosystems AG, CH-9435 Heer- Environment: brugg (he...
Page 18
Responsibilities of the person in charge of the equip- International Warranty, Software License ment: Agreement WARNING: International Warranty The person responsible for the equipment must The Intern...
Page 19
You must not install or use the software unless you have Hazards of use read and accepted the terms and conditions of the Leica Geosystems Software License Agreement. Installation or Main hazards of u...
Page 20
Precautions: observed. Before transportation or shipping contact your Adhere to the instructions given by the computer manufac- local passenger or freight transport company. turer with regard to field...
Page 21
WARNING: WARNING: Inadequate securing of the survey site can lead to During dynamic applications, for example stakeout dangerous situations, for example in traffic, on procedures there is a danger of ...
Page 22
By disposing of the equipment irresponsibly you may Always follow the regulations in force in your country enable unauthorized persons to use it in contravention with regard to grounding Antennas and ...
Page 23
Suggestion for design of a Lightning Conductor for a Air Terminal arrangement (plan view) GPS System 1. On non-metallic structures Protection by Air Terminals is recommended. An Air Terminal is a poin...
Page 24
Grounding the Receiver/Antenna Electromagnetic Compatability (EMC) The term "electromagnetic compatability" is taken to mean the capability of the product to function smoothly in an envi- ro...
Page 25
CAUTION: Use of the product with internal (BLUETOOTH) and Disturbances caused by electromagnetic radiation external Radio devices: can result in the tolerance limits for measurements being exceeded. W...
Page 26
WARNING: FCC statement (applicable in U.S.) This Bluetooth transmitter must not be operating in conjunction with any other transmitter or transmitting WARNING: antenna. This equipment, including SR20 ...
Page 27
WARNING: Labelling internal battery GEB90: Changes or modifications not expressly approved by Leica Geosystems for compliance could void the The label indicator is placed on the backside of the device...
Page 28
6. Technical Data Tracking Characteristics Interface Satellite Reception Port 1 Single frequency Conformable with RS232 Receiver channels Lemo 7 Pin 12 L1 continuous tracking BLUETOOTH Specification L...
Page 29
Equipment weights Separation distances Receivers Leica SR20 to AT501 RTB or RTS Antenna Leica SR20 0.55 kg Supplied cables:................................................... 1.2m Wo RCS RTB 1.45 kg L...
Page 30
Conformity to national regulations FCC part 15 (applicable in U.S.) European directive 1999/5/EC on radio equipment and telecommunications terminal equipment (see CE Conformity Declaration). The confo...
Page 31
Technical Data31Leica SR20 User Manual-1.0.0en
Page 32
Leica Geosystems AG, Heerbrugg, Total Quality Management- Switzerland, has been certified as Our commitment to total being equipped with a quality system customer satisfaction. which meets the Interna...
